Mitsubishi MELSEC-A A1SHCPU User Manual

60
Model Type
No. of
Points
Rated Input
Voltage
Input
Current
Operating Voltage
ON voltage OFF voltage
A1SX71
DC input
(sink/source
type)
32 5/12/24VDC
1.2/3.3/
7mA
3.5VDC or
higher
1VDC or lower
A1SX80
16
12/24VDC 3/7mA
8VDC or
higher
4VDC or lower
A1SX80-S1 24VDC
7mA
17VDC or
higher
5VDC or lower
A1SX80-S2 24VDC
13VDC or
higher
6VDC or lower
A1SX81
32
12/24VDC 3/7mA
8VDC or
higher
4VDC or lower
A1SX81-S2 24VDC 7mA
13VDC or
higher
6VDC or lower
A1SX82-S1 64 24VDC 5mA
18.5VDC or
higher
3VDC or lower
A1S42X
DC input
(dynamic)
*2
16/32
48/64
12/24VDC 4/9mA
8VDC or
higher
4VDC or lower
