Mitsubishi MELSEC-A A2ASCPU-S1 User Manual

6 - 2
6. BASE UNIT AND EXTENSION CABLE
6.1.2 Extension cable specifications
The specifications of the extension cables applicable to PLC systems are shown in Table
6.3.
When using the extension cable, do not bundle it with the main circuit cables
together, which has high voltage, large current, or install them close to each other.
Table 6.3 Extension cable specifications
Item A1SC01B A1SC03B A1SC07B A1SC12B A1SC30B A1SC60B A1SC05NB A1SC07NB A1SC30NB A1SC50NB
Cable length
0.055m
(0.18ft.)
0.33m
(1.08ft.)
0.7m
(2.30ft.)
1.2m
(3.94ft.)
3.0m
(9.84ft.)
6.0m
(19.69ft.)
0.45m
(1.48ft.)
0.7m
(2.30ft.)
3.0m
(9.86ft.)
5.0m
(16.43ft.)
Resistive value of
5VDC supply line
(at 55 )
0.02 0.02 0.04 0.06 0.12 0.18 0.04 0.05 0.12 0.18
Application
Connection between a main base and A1S5 B(S1)/A1S6 B(S1) Connection between a main base and A5 B/A6 B
Weight 0.025kg 0.10kg 0.14kg 0.20kg 0.40kg 0.65kg 0.20kg 0.22kg 0.40kg 0.56kg
