2 - 16
SYSTEM CONFIGURATION2.
Blank cover A1SG60 Dust-proof cover for unused slot 16 [Empty] – –
Dummy module A1SG62
16-point, 32-point, 48-point, 64-point selectable
module
Specified number of
points
[Input
]
––
Pulse catch
module
A1SP60
Short ON-time pulse input module
(pulse with a minimum of 0.5ms) 16 input
points
16
[16 output
points]
0.055 –
Analog timer
module
A1ST60
A module whose timer setting value can be
changed for different volumes (0.1 to 1.0s,1 to
10s,10 to 60s,60 to 600s)
Analog timer 8 points
16
[16 output
points]
0.055 –
Interrupt module A1SI61
Interrupt module for specifying the interrupt
program
(16-point interrupt input)
32
[32 special
points]
0.057 –
High-speed
counter module
A1SD61
32-bit signed binary
50kBPS, 1 channel
32
[32 special
points]
0.35 –
A1SD62
24-bit signed binary, 2 channel
100kPPS, DC input
transistor output (sink type)
32
[32 special
points]
0.1 –
A1SD62D
24-bit signed binary, 2 channel
200kPPS, difference input
transistor output (sink type)
32
[32 special
points]
0.25 –
A1SD62D-S1
24-bit signed binary, 2 channel
200kPPS, difference input
transistor output (sink type)
32
[32 special
points]
0.27 –
A1SD62E
24-bit signed binary, 2 channel
100kPPS, DC input
transistor output (source type)
32
[32 special
points]
0.1 –
A/D converter
module
A1S64AD
4 to 20mA/0 to 10V
4 analog channels
32
[32 special
points]
0.4 –
A1S68AD
4 to 20mA/0 to 10V
8 analog channels
32
[32 special
points]
0.4 –
D/A converter
module
A1S62DA
4 to 20mA/0 to 10V
2 analog output channels
32
[32 special
points]
0.8 –
A1S68DAV
-10 to 10V input
8 analog output channels
32
[32 special
points]
0.65 –
A1S68DAI
4 to 20mA input
8 analog output channels
32
[32 special
points]
0.85 –
Analog I/O
module
A1S63ADA
Analog input, 2 channels, simple loop control is
allowed.
1 analog output channels
32
[32 special
points]
0.8 –
A1S66ADA
Analog input, 4 channels, simple loop control is
allowed.
2 analog output channels
64
[64 special
points]
0.21 0.16
Product Name Model Name Description
Number of occupied
points (points)
[I/O allocation
module type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
Specified number of points
To Next Page
