4 - 23
CPU MODULE4.
*1 The capacity for network parameters of MELSECNET/10 changes depending on the contents
set.
The area for the network parameters shall be secured in 2k byte units based on the total of
capacity for each setting.
The memory capacity of each network parameter is as follows:
*2 If the MELSECNET(II) data link system is configured using a GPP function software package
for the AnU, 2k bytes (for 1k step) are occupied as a link parameter area.
Item Memory capacity (bytes)
Internal data 30
Routing parameter 390
Transfer parameter between data links 246
Common parameter
Control station 2164/module
Remote master
station
2722 bytes
Refresh parameter 92/module
Station inherent parameter 1490/module
The network parameter capacity for MELSECNET/10 is determined from the total of the
memory capacities calculated from above.
Total of the capacity
Capacity of the network parameter
setting
30 to 2048 bytes 2k bytes
2049 to 4096 bytes 4k bytes
4097 to 6144 bytes 6k bytes
6145 to 8192 bytes 8k bytes
8193 to 10240 bytes 10k bytes
10241 to 12288 bytes 12k bytes
12289 to 14336 bytes 14k bytes
14337 to 16384 bytes 16k bytes
