4 - 32
CPU MODULE4.
Item
Memory
capacity
Head address for storing Remark
Parameter, T/C set value 4k bytes 0k
Main program
Sequence program 30k bytes 4k
Microcomputer program 0k byte –
MELSECNET/10 network parameter 2k bytes 34k
Not used area (12k) (36k)
Extension file
register
Block No.8 16k bytes –
Block No.7 16k bytes –
Because the empty memory capacity is 12k
bytes, extension file registers can be only used 1
block.
Block No.6 16k bytes –
Block No.5 16k bytes –
Block No.4 16k bytes –
Block No.3 16k bytes –
Block No.2 16k bytes –
Block No.1 16k bytes 48k
File register
(d)
*1
64k
Comment
(e)
*1
80k
Extension file
register
Block No.16 16k bytes 144k
Block No.15 16k bytes 160k
Block No.14 16k bytes 176k
Expanded
comment
Block No.13 16k bytes 192k
Expanded comments are stored to No.10
through No.13 due to short of block No.1 to 8
area memory capacity.
Block No.12 16k bytes 208k
Block No.11 16k bytes 224k
Block No.10 16k bytes 240k
To Next Page
