4 - 27
CPU MODULE4.
(c) Stored address of user memory
Data address for storing to RAM memory can be calculated as follows.
Note that confirm the data destination address as follows so as not to protect the
data destination switched.
1) During RAM operation
Item
Memory
capacity
Head address for storing to RAM memory
Remark
A2USHCPU-S1
A2USCPU-S1
A2ASCPU-S30
A2ASCPU-S1
A2USCPU
A2ASCPU
Parameter, T/C set value 4k bytes 0k 0k
Main program
Sequence program
(a)
*1
4k 4k
Microcomputer program
(b)
*1
4k + (a) 4k + (a)
MELSECNET/10 network parameter
(c)
*1
4k + (a) + (b) 4k + (a) + (b)
Expanded comment
*2
(f)
*1
4k + (a) + (b) + (c) 4k + (a) + (b) + (c)
Not used area – 4k + (a) + (b) + (c) + (f) 4k + (a) + (b) + (c) + (f)
Extension file
register
*3
Block No.8 16k bytes 16k - (d) - (e) –
Number of extension file
registers: n can be
determined by the rest of
the memory capacity
after storing parameters,
T/C set values, main
programs, MELSECNET/
10 network parameters,
file registers,
comments.
*4
Block No.7
*2
16k bytes 32k - (d) - (e) –
Block No.6 16k bytes 48k - (d) - (e) –
Block No.5 16k bytes 64k - (d) - (e) –
Block No.4 16k bytes 80k - (d) - (e) –
Block No.3 16k bytes 96k - (d) - (e) 16k - (d) - (e)
Block No.2 16k bytes 112k - (d) - (e) 32k - (d) - (e)
Block No.1 16k bytes 128k - (d) - (e) 48k - (d) - (e)
File register
(d)
*1
144k - (d) - (e) 64k - (d) - (e)
Comment
(e)
*1
144k-(e) 64k-(e)
Extension file
register
*3
Block No.16 16k bytes 144k –
Block No.15 16k bytes 160k –
Block No.14 16k bytes 176k –
Block No.13 16k bytes 192k –
Block No.12 16k bytes 208k –
Block No.11
*2
16k bytes 224k –
Block No.10 16k bytes 240k –
