Mitsubishi MUX-2A28VB User Manual

28
OUTDOOR UNIT
INDOOR UNIT
UNIT A
Indoor
heat
exchanger
Indoor coil
thermistor
RT12
Room
temperature
thermistor
RT11
UNIT B
Indoor
heat
exchanger
Outdoor
heat
exchanger
Indoor coil
thermistor
RT12
Room
temperature
thermistor
RT11
Flared connection
(With insulation)
Refrigerant pipe
[6.35
(With insulation)
Refrigerant pipe
[6.35
Flared connection
Stop valve
with service port
Stop valve
Stop valve
with
service port
Capillary tube
Capillary tube
Muffler
Muffler
Strainer
#100
Compressor(A)
Compressor(B)
Refrigerant flow in cooling
(With insulation)
Refrigerant pipe
[9.52
(With insulation)
Refrigerant pipe
[9.52
Stop valve
[3.0 x [1.4 x 700
[3.0 x [1.4 x 700
Strainer
#100
MUX-2A70VB-
E1
Unit : mm
OB384--1.qxp 05.1.17 13:08 Page 28
