5
PART NAMES AND FUNCTIONS
2
Air outlet
Drain outlet
Piping
Drain hose
Air inlet
(back and side)
MUZ-A09NA MUZ-A15NA MUY-A15NA
MUZ-A12NA MUZ-A17NA MUY-A17NA
MUZ-A24NA
MUY-A24NA
Piping
Air outlet
Drain hose
Drain outlet
Air inlet
(back and side)
OB451--1.qxp 06.3.29 9:51 AM Page 5
