32
Your company internal use only.Copyright (C) Mitsubishi Electric Corporation.
NR-261UM-07LAN4,-07-5WS
PARTS LIST
* Marked part is the ASSY replacement.
Ref. No. Parts No. Parts Name Page Ref. No. Parts No. Parts Name Page
M001 241L91810 FPC-CON P.19 M051 707L24214 PANEL-HDD P.10
M002 241L91910 FPC-DVD P.23 M052 734K03710 BUTTON-VOL P.29
M003 210K45110 FPC P.27 M053 734K03810 BUTTON-SCALE P.29
M004 246L55611 FLAT-CABLE 30P P.19 M054 734K03910 BUTTON-MODE P.29
M005 246L45025 FLAT-CABLE 50P P.25 M055 734K04010 BUTTON-AUDIO P.29
M006 246L45026 FLAT-CABLE 50P P.19,20 M056 734K04110 BUTTON-PWR P.29
M007 246L47112 LEAD-CONNECTOR 4P P.17 M057 734K04210 BUTTON-SET P.29
M008 246L47226 FLAT-CABLE 8P P.27 M058 734K04310 BUTTON-OPEN P.29
M009 246L47227 FLAT-CABLE 8P P.29 M059 734K04410 BUTTON-INFO P.29
M010 288P08415 MOTOR-FAN P.13 M060 734K04510 BUTTON-NAVI P.29
M011 560J33413 CHASSIS-ANALOG P.20 M061 734K04610 BUTTON-MENU P.29
M012 560K29023 CHASSIS-L P.15 M062 761L62110 PRISM P.29
M013 590J39812 PLATE P.22 M063 850L96010 LABEL P.26
M014 590J42711 PLATE-LCD P.31 M064 851L262O4 LABEL-CAUTION P.24
M015 591K54511 CASE-DIGITAL P.16 M065 890P11220 ASSY-LCD P.31
M016 591K56610 COVER-TOP P.11 M066 890P11813 ASSY-PANE P.30
M017 591K56710 BRACKET-DV3F P.24 M067 891K25210 ASSY-SHIELD P.16
M018 591K56811 PLATE-HS P.24 M068 891L65816 ASSY-COVER-F P.10
M019 591K62910 PLATE-T-PANEL P.30 M069 892J02655 ASSY-SLIDE P.21,22
M020 593L68211 HOLDER-HDD P.25 M070 892K52111 ASSY-PANEL-SUB P.12
M021 593L75210 BRACKET-NAVI P.18 M071 892L45330 ASSY-PANEL-F P.29
M022 593L75310 HOLDER-HDD P.25 M072 892L45412 ASSY-PANEL-R P.26
M023 593L75420 BRACKET-DV3R P.24 M073 892L45512 ASSY-ENT P.26
M024 630L36511 PIN-MONI P.10 M074 937L39313 ASSY-ROM(HDD) P.25
M025 635J09611 HEAT-SINK P.13 *M075 940L42710 DV3DP(950850) P.24
M026 641K40412 COVER-DV3 P.23 M076 943M216O2 ASSY-PCB-PANEL P.12
M027 643L15011 SHEET-BTM P.22 M077 943M268O1 ASSY-PCB-DIGITAL P.16
M028 643L15110 SHEET-HDD P.25 M078 943M268O2 ASSY-PCB-HDD P.25
M029 643L41915 SHEET-HS P.16 M079 943M330O5 ASSY-PCB-AUDIO P.21
M030 643L41916 SHEET-HS P.24 M080 943M330O6 ASSY-PCB-GPS P.22
M031 643L47510 SHEET-ANALOG P.20 M081 943M330O7 ASSY-PCB-ANALOG P.17,18,19
M032 643L47610 SHEET-COIL P.20 M082 943M330O8 ASSY-PCB-CONN P.14
M033 643L47811 SHEET-AUDIO P.21 M083 943M330O9 ASSY-PCB-SENSOR P.17
M034 643L47910 SHEET-FRONT P.23 M084 943M331O1 NAME-CARD(NR-261UM-07LAN4) P.10
M035 643L55410 SHEET-DI P.16 M085 943M331O2 NAME-CARD(NR-261UM-07-5WS) P.10
M036 643L60310 SHEET-DVD P.24 M086 967L15127 S2-MONI P.10
M037 643L60812 SHEET P.30 M088 643L60821 SHEET P.26
M038 643L60813 SHEET P.30 A 653P01046 SCREW-MC-PAN M3X6 -
M039 643L60815 SHEET P.26 B 653P01446 SCREW-MC-PAN M3X6 -
M040 643L60816 SHEET P.31 C 653P03026 SCREW-MC-BIND 2.6X4 -
M041 643L60817 SHEET P.30 D 653P03425 SCREW-MC-BIND M2.6X3 -
M042 643L60818 SHEET P.30 E 653P06027 SCREW-MC-SEMS M2.6X6 -
M043 643L60819 SHEET P.29 F 653P21662 SCREW-B-PAN 2X4 -
M044 643L60820 SHEET P.31 G 653P21766 SCREW-B-PAN 2X6 -
M045 643L60910 SHEET-L P.31 H 653P41616 SCREW-MC-PAN 2X8 -
M046 643L61010 SHEET-FPC P.27 J 669L11110 SCREW-TAP 2X4 -
M047 643L61110 SHEET-LCD P.29 K 669L11210 SCREW-SEMS M3X10 -
M048 643L61210 SHEET-B P.31 L 669L12610 SCREW-FH M3X4 -
M049 643L61310 SHEET-ENT P.26 M 669L13710 SCREW-S-BIND 2X4 -
M050 645L21310 PLATE-HDD P.25
To Next Page
