7-16
Vehicle care and maintenance
7
5. For 2.4 L models, put the duct back on in its original posi-
tion.
Automatic transaxle fluid (if so equipped)
N00938000570
The automatic transaxle should be maintained and serviced by
an authorized Mitsubishi Motors dealer or a repair facility of
your choice to obtain the best performance and longest life. It
is important that the transaxle fluid is kept at the correct level.
To check the fluid level
The fluid level should be checked when the bar graph for the
engine coolant temperature display on the multi-information
display shows the engine is warmed up and the fluid in the
transaxle is heated to its normal working temperature. Driving
with the wrong fluid level will rapidly wear out the transaxle
and destroy the fluid.
CAUTION
!
● Take care not to scratch the engine air flow sensor
when removing the air cleaner cover.
3.0 L models
BK0150600US.book 16 ページ ２０１２年３月３０日 金曜日 午前１０時４３分
