NOTE
l
If you are unsure of how to carry out the
work as required, we recommend you to
consult a specialist.
l
Be careful not to scratch the vehicle body
when removing a lamp or lens.
l
When it rains or when the vehicle has been
washed, the inside of the lens sometimes be-
comes foggy. This is the same phenomenon
as when window glass mists up on a humid
day, and does not indicate a functional prob-
lem.
When the lamp is switched on, the heat will
remove the fog. However, if water gathers
inside the lamp, we recommend you to have
the lamp checked.
Bulb location and capacity
E01003200333
When replacing a bulb, use a new bulb with
the same wattage and colour.
Outside
E01003304563
Type A: Except for high intensity discharge
headlamp type
Type B: High intensity discharge headlamp
type
1- Front turn-signal lamps: 21 W (PY21W)
2- Headlamps, high-beam: 60 W (HB3)
3- Headlamps, low beam
l
Halogen: 55 W (H7)
l
LED: −
4- Position lamps/ Daytime running lamps:
−
5- Front fog lamps*: 19 W (H16)
6- Side turn-signal lamps (on fender)*: 5 W
7- Side turn-signal lamps (on outside rear-
view mirror)*
Codes in parentheses indicate bulb types.
NOTE
l
It is not possible to repair or replace only the
bulb for the side turn-signal lamp (on fend-
er).
For repair and replacement, contact a
MITSUBISHI MOTORS Authorized Serv-
ice Point.
l
The following lamps use an LED instead of
the bulb.
If you need to repair or replace these lamps,
contact a MITSUBISHI MOTORS Author-
ized Service Point.
•
Headlamps, low beam (LED type)
•
Position lamps
•
Daytime running lamps
•
Side turn-signal lamps (on outside rear-
view mirror)
Replacement of lamp bulbs
10-24
OGFE16E1
Maintenance
10
