4. To install the bulb, perform the removal
steps in reverse.
Front turn-signal lamps
E01003802290
1. Remove the 12 clips (A, B), and then re-
move the cover (C).
2. Turn the socket (D) anticlockwise to re-
move it, then remove the bulb from the
socket by turning it anticlockwise while
pressing in.
*: Front of the vehicle
3. To install the bulb, perform the removal
steps in reverse.
Front fog lamps*
E01004003182
1. Insert a straight blade (or minus) screw-
driver with a cloth over its tip at the
points indicated by arrows and pry gen-
tly to remove the cover (A).
2.
Remove the 3 screws (B) and remove
the lamp unit.
Replacement of lamp bulbs
10-27
OGFE16E1
Maintenance
10
