*: Front of the vehicle
3. Turn the socket (C) anticlockwise to re-
move it, and then pull the bulb out of the
socket.
4. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the bulb, align the tab (D)
with the notch (E) of the socket.
Headlamps (high-beam)
E01009401275
1. When replacing the bulb on the right
side of the vehicle, remove the clip (A)
holding down the washer tank spout and
move the spout towards the rear of the
vehicle.
2. Turn the cap (B) anticlockwise to re-
move it.
*: Front of the vehicle
3. Turn the bulb (C) anticlockwise to re-
move it, and then while holding down
the tab (D), pull out the bulb (E).
Replacement of lamp bulbs
10-26
OGFE16E1
Maintenance
10
