NOTE
l
When unfastening the screws of the fog
lamp, be careful not to mistakenly move the
beam position adjustment screw (C).
3. While holding down the tab (D), pull out
the socket (E).
4. Turn the bulb (F) anticlockwise to re-
move it.
5. To install the bulb, perform the removal
steps in reverse.
Rear fog lamp (driver’s side)/
Reversing lamp (Passenger’s
side)
E01004101655
1. Insert a straight blade (or minus) screw-
driver with a cloth over its tip at the edge
of the lamp unit, and then push the lamp
unit upward to remove it.
Replacement of lamp bulbs
10-28
OGFE16E1
Maintenance
10
