D- Rear turn-signal lamp
E- Tail lamp and stop lamp (LED)-cannot
be replaced
NOTE
l
The tail lamp and stop lamp use an LED in-
stead of the bulb.
If you need to repair or replace these lamps,
contact a MITSUBISHI MOTORS Author-
ized Service Point.
4. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the lamp unit, align the
notch (F) and pin (G) on the lamp unit with
the clip (H) and hole (I) in the body.
Licence plate lamps
E01004600679
1. Remove while pressing the lamp unit
(A) to the left side of the vehicle.
2. Insert a minus screwdriver with the end
covered with a cloth or other object to
press the hook (B) aside and remove the
lens.
3. Remove the bulb from the socket.
4. To install the bulb, perform the removal
steps in reverse.
Replacement of lamp bulbs
10-30
OGFE16E1
Maintenance
10
