Second-centre 3-point type seat
belt
E00405201155
The second-centre 3-point type seat belt must
be worn correctly as illustrated.
WARNING
l
Be sure to securely connect the both latch
plate (A and B). Failing to do so could sig-
nificantly reduce the amount of protection
and cause serious injures in a collision or
a sudden stop.
NOTE
l
If the seat belt buckles in the second seating
position are not found, you will find them
under the second seat cushion.
Refer to “Folding the second seats” on page
4-08 for putting the seat belt buckles at the
proper position.
To fasten
1. Pull out the buckle (C) from the seat-
back.
2. Pull out the small latch plate (A) and
then pull out the latch plate (B) by tilting
it as shown in the illustration.
NOTE
l
Pulling out the latch plate by force may
damage the headliner.
3. Pull the seat belt and insert the small
latch plate (A) into the buckle (C).
4. Insert the latch plate (B) into the buckle
(D).
5. Pull the belt slightly to adjust slackness
as desired.
To unfasten
1. Hold the latch plate and push the button
on the buckle.
NOTE
l
As the belt retracts automatically, keep hold-
ing the latch plate while retracting so that the
belt stows slowly. Failure to do this could
damage the vehicle.
l
To release the buckle (C), press the button
(E) with a narrow-tipped object (latch plate
or mechanical key etc.).
Seat belts
4-15
OGFE16E1
Seats and seat belts
4
