Except on vehicles with a T155/90D16 size spare
wheel
1. Open the tailgate and remove the cover (A)
with the jack bar. Refer to “Split tailgate: To
open” on page 1-31.
2. Insert the wheel nut wrench in the hole and
lower the standard spare wheel by turning it
anticlockwise.
3. Raise the lower gate until it locks properly in
position with a click. Refer to “Split tailgate:
To close” on page 1-31.
4. Remove the chain from the spare tyre hanger.
5. Take out the standard spare wheel from the
spare tyre hanger.
To change a tyre
E00803200712
1. If a wheel cover is installed, first remove the
cover. (Refer to “Wheel covers” on page
6-18.)
Then loosen the wheel nuts a quarter turn
with the wheel nut wrench. Do not remove
the wheel nuts yet.
2. Place the jack under one of the jacking
points (A) shown in the illustration. Use the
For emergencies
6-12
6
