WARNING
l
When lifting up the third seat, do not put
your hands in the areas indicated by the
red labels (D). You could trap your fin-
gers in the seat hinge and be injured.
8. Return the cover to its position.
Lightly push the seat and seatback to make
sure they are set firmly in place.
To retract
1. Open the tailgate. Refer to “Split tailgate” on
page 1-31.
2. Pull up the cover (A) from the rear direction.
Fasten the pulled up cover to the seatback
with the band (B).
3. Slide the knob (C) while folding the head re-
straint to the rear, and stow to the front one
side at a time.
4. Stow the whole of the third seat under the
floor while pulling the belt (D- grey).
CAUTION
l
Do not put your hands on the end trim
(E) when stowing the third seat under the
floor. Doing so could trap and injure
your hand.
NOTE
l
Push down on the rear of the third seat until
it is securely locked to the floor.
Seats and seat belts
2-12
2
