Terminal block for
indoor and outdoor
unit connection
Terminal block for power line
Ground
terminal
Handle
for moving
Service panel
Refrigerant pipe (Flared)
PU24EK [5/8
PU30EK [3/4
Knock out hole
for front piping
4-3/4
(refrigerant. drainage
and wiring)
4-1/8
Drain hole
Drain hole
2-U-shaped
notched
holes
2-1/16
2-1/4
1-9/16
Bottom
piping hole
2-9/16
3-1/8
R13/16
Front right piping holes-
detail figures
Standard bolt length
1 max.
1/2
2-1/2x7/8 Oval holes
(standard bolt M10)W3/8(M10)
Knock out hole
for right piping
(refrigerant.
drainage and wiring)
3-1/4
20-5/8 20-5/82-3/8
13-9/16 23-1/16
1
2
15-1/16
37-34
2-3/820-5/81-9/16
49-9/16
34-1/4
11-7/8
7-9/32 7-9/32
Front opening
Service space
(for N.E.C)
3/8
36
36
4
Note:Allow adequate
upper clearance.
Outdoor Unit - necessary surrounding clearance
1/2
12
1/2
1-9/161-1/16
13
14-1/4
11/169/16
19-11/16
Refrigerant pipe (Flared)
PU24EK [3/8
PU30EK [1/2
Outlet guide
installation hole
1
40
1/2
Outdoor Unit-Necessary surrounding clearance
(Concentrated installation)
The upper side must be open.
6
12
For 10 units or less
11-5/81/4
Side air intake
Handle
for moving
Rear fresh
air intake
Rear piping hole
Handle for moving
3-3/4
5-7/16
2-3/8
Knock out holes for
power line 1-1/16
1-3/4
2-1/16
Air intake
Air intake
Air outlet
11/16
R1/4
R13/16
15-7/8
