Mitsubishi PUG30AYB User Manual

036-21534-001 Rev. B (0703)
12 Mitsubishi Electronics 2003
PL24+PUG24 (Indoor Air = 710 CFM)
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 21,002 8.23 2,552 16,693 20,662 24,631 28,600 32,569 75 299
65 22,501 8.62 2,609 14,524 18,493 22,462 26,431 30,400 80 303
67 24,000 9.00 2,667 12,355 16,324 20,293 24,262 28,231 85 307
69 24,899 9.28 2,683 10,116 14,085 18,054 22,023 25,992 85 309
71 25,798 9.56 2,698 7,877 11,845 15,814 19,783 23,752 85 310
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 19,216 7.09 2,710 15,878 19,847 23,816 27,785 31,754 79 338
65 20,518 7.45 2,755 13,903 17,872 21,841 25,810 29,779 83 320
67 21,819 7.79 2,800 11,928 15,897 19,866 23,835 27,804 87 302
69 23,003 8.13 2,829 9,701 13,670 17,639 21,608 25,577 88 324
71 24,186 8.46 2,857 7,474 11,443 15,412 19,381 23,350 89 346
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 17,431 6.08 2,867 15,064 19,033 23,002 26,971 30,940 83 376
65 18,534 6.39 2,900 13,283 17,252 21,221 25,190 29,159 86 336
67 19,638 6.69 2,933 11,502 15,471 19,440 23,409 27,378 89 296
69 21,106 7.09 2,975 9,287 13,256 17,225 21,194 25,163 91 339
71 22,574 7.48 3,016 7,072 11,041 15,010 18,979 22,948 93 382
105 F Outdoor Air Temperature
Indoor Wet
Bulb (F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/Hr)
Pressures
(psig)
Indoor Dry Bulb ( F)
70 75 80 85 90 Suction Disch.
63 19,216 7.09 2,710 13,506 17,475 21,444 25,413 29,382 79 338
65 20,518 7.45 2,755 12,013 15,982 19,951 23,920 27,889 83 320
67 21,819 7.79 2,800 10,520 14,489 18,458 22,426 26,395 87 302
69 23,003 8.13 2,829 8,456 12,425 16,394 20,363 24,332 88 324
71 24,186 8.46 2,857 6,392 10,361 14,330 18,299 22,268 89 346
115 F Outdoor Air Temperature
Indoor Wet
Bulb (F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/Hr)
Pressures
(psig)
Indoor Dry Bulb ( F)
70 75 80 85 90 Suction Disch.
63 17,431 6.08 2,867 11,948 15,917 19,886 23,855 27,824 83 376
65 18,534 6.39 2,900 10,742 14,711 18,680 22,649 26,618 86 336
67 19,638 6.69 2,933 9,537 13,506 17,475 21,444 25,413 89 296
69 21,106 7.09 2,975 7,624 11,593 15,562 19,531 23,500 91 339
71 22,574 7.48 3,016 5,712 9,681 13,650 17,619 21,587 93 382
PERFORMANCE DATA - OPERATING PRESSURES
4
