PL18+PUG18 (Indoor Air = 600 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Disch.
63 19,879 12.21 1,629 11,583 14,989 18,395 21,801 25,207 71 200
65 20,894 12.72 1,643 10,125 13,532 16,938 20,344 23,750 73 204
67 21,477 12.95 1,658 8,668 12,074 15,480 18,886 22,293 75 208
69 22,451 13.50 1,663 6,954 10,360 13,766 17,172 20,578 81 210
71 22,913 13.73 1,668 5,240 8,646 12,052 15,458 18,864 86 212
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 18,970 10.86 1,746 11,093 14,499 17,905 21,311 24,717 75 233
65 19,823 11.24 1,764 9,760 13,166 16,573 19,979 23,385 77 236
67 20,739 11.64 1,781 8,428 11,834 15,240 18,646 22,052 80 240
69 21,600 12.06 1,790 6,639 10,045 13,451 16,857 20,263 84 241
71 22,173 12.32 1,799 4,850 8,256 11,662 15,068 18,474 88 243
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 18,060 9.69 1,863 10,603 14,009 17,415 20,821 24,227 79 265
65 18,751 9.95 1,884 9,395 12,801 16,207 19,613 23,020 82 268
67 20,000 10.50 1,905 8,188 11,594 15,000 18,406 21,812 84 271
69 20,749 10.82 1,918 6,324 9,730 13,136 16,542 19,948 87 273
71 21,432 11.10 1,931 4,460 7,867 11,273 14,679 18,085 89 274
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 16,787 8.43 1,992 9,300 12,706 16,112 19,518 22,924 84 303
65 17,098 8.52 2,007 8,455 11,861 15,267 18,673 22,079 86 305
67 18,264 9.03 2,022 7,610 11,016 14,422 17,828 21,235 88 308
69 19,169 9.38 2,044 5,754 9,160 12,566 15,972 19,378 90 310
71 20,018 9.69 2,066 3,898 7,304 10,710 14,116 17,522 93 313
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 15,514 7.32 2,121 7,997 11,403 14,809 18,215 21,621 89 341
65 15,445 7.25 2,130 7,515 10,921 14,327 17,733 21,139 90 343
67 16,528 7.73 2,138 7,033 10,439 13,845 17,251 20,657 91 344
69 17,588 8.11 2,170 5,184 8,590 11,996 15,402 18,808 94 348
71 18,603 8.45 2,202 3,335 6,741 10,147 13,553 16,959 97 352
