Mitsubishi PUG30AYB User Manual

036-21534-001 Rev. B (0703)
10 Mitsubishi Electronics 2003
PK36+PUG36 (Indoor Air = 990 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 35,104 12.32 2,849 20,676 24,068 28,785 33,502 36,894 67 222
65 36,163 12.56 2,879 18,194 21,586 26,303 31,020 34,412 69 219
67 37,221 12.80 2,908 15,712 19,104 23,821 28,538 31,930 70 215
69 38,491 13.19 2,918 13,543 16,935 21,652 26,369 29,761 71 216
71 39,760 13.58 2,928 11,373 14,765 19,482 24,199 27,591 72 217
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 32,861 10.90 3,014 19,756 23,148 27,865 32,582 35,974 70 249
65 34,286 11.17 3,068 17,336 20,728 25,445 30,162 33,554 72 249
67 35,711 11.44 3,122 14,917 18,309 23,026 27,743 31,135 74 250
69 36,865 11.74 3,140 12,719 16,111 20,828 25,545 28,937 75 251
71 38,020 12.04 3,158 10,521 13,913 18,630 23,347 26,739 77 252
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 30,618 9.63 3,179 18,835 22,227 26,944 31,661 35,053 72 275
65 32,409 9.94 3,258 16,478 19,870 24,587 29,304 32,696 75 280
67 34,200 10.25 3,337 14,121 17,513 22,230 26,947 30,339 77 285
69 35,240 10.48 3,362 11,895 15,287 20,004 24,721 28,113 79 286
71 36,280 10.71 3,387 9,668 13,060 17,777 22,494 25,886 81 287
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 27,936 8.32 3,358 17,359 20,751 25,468 30,185 33,577 76 314
65 29,667 8.63 3,438 15,258 18,650 23,367 28,084 31,476 79 318
67 31,398 8.93 3,518 13,158 16,550 21,267 25,984 29,376 83 323
69 32,844 9.21 3,565 11,006 14,398 19,115 23,832 27,224 84 324
71 34,290 9.49 3,612 8,855 12,247 16,964 21,681 25,073 86 326
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 25,254 7.14 3,537 15,882 19,274 23,991 28,708 32,100 79 353
65 26,925 7.44 3,618 14,038 17,430 22,147 26,864 30,256 84 357
67 28,596 7.73 3,699 12,194 15,586 20,303 25,020 28,412 88 360
69 30,448 8.08 3,768 10,118 13,510 18,227 22,944 26,336 89 363
71 32,300 8.42 3,836 8,041 11,433 16,150 20,867 24,259 90 365
PERFORMANCE DATA - OPERATING PRESSURES
