036-21534-001 Rev. B (0703)
Mitsubishi Electronics 2003 9
PK30+PUG30 (Indoor Air = 990 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 29,702 12.28 2,419 18,029 21,421 26,138 30,855 34,247 72 224
65 30,517 12.57 2,428 15,612 19,004 23,721 28,438 31,830 73 225
67 31,331 12.85 2,438 13,196 16,588 21,305 26,022 29,414 74 225
69 32,153 13.08 2,458 10,787 14,179 18,896 23,613 27,005 76 228
71 32,974 13.31 2,477 8,378 11,770 16,487 21,204 24,596 78 230
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 27,689 10.81 2,561 17,027 20,419 25,136 29,853 33,245 75 256
65 28,977 11.12 2,606 14,822 18,214 22,931 27,648 31,040 77 260
67 30,266 11.42 2,650 12,618 16,010 20,727 25,444 28,836 79 264
69 31,255 11.73 2,665 10,394 13,786 18,503 23,220 26,612 81 265
71 32,245 12.03 2,680 8,171 11,563 16,280 20,997 24,389 83 267
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 25,675 9.50 2,703 16,026 19,418 24,135 28,852 32,244 77 287
65 27,438 9.85 2,783 14,032 17,424 22,141 26,858 30,250 81 295
67 29,200 10.20 2,863 12,039 15,431 20,148 24,865 28,257 84 302
69 30,358 10.57 2,873 10,001 13,393 18,110 22,827 26,219 86 303
71 31,515 10.93 2,883 7,964 11,356 16,073 20,790 24,182 88.5 303
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 23,599 8.95 2,635 14,612 18,004 22,721 27,438 30,830 81 326
65 25,183 8.95 2,813 12,912 16,304 21,021 25,738 29,130 83 331
67 26,768 8.95 2,991 11,212 14,604 19,321 24,038 27,430 86 337
69 28,268 9.31 3,035 9,213 12,605 17,322 22,039 25,431 89 339
71 29,769 9.67 3,078 7,213 10,605 15,322 20,039 23,431 92 342
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 21,522 8.38 2,568 13,198 16,590 21,307 26,024 29,416 84 364
65 22,929 8.09 2,844 11,792 15,184 19,901 24,618 28,010 86 368
67 24,335 7.80 3,120 10,386 13,778 18,495 23,212 26,604 88 372
69 26,179 8.18 3,197 8,424 11,816 16,533 21,250 24,642 92 376
71 28,022 8.56 3,274 6,462 9,854 14,571 19,288 22,680 96 380
PERFORMANCE DATA - OPERATING PRESSURES
4
