Mitsubishi PUG30AYB User Manual

036-21534-001 Rev. B (0703)
8 Mitsubishi Electronics 2003
PK24+PUG24 (Indoor Air = 640 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 23,389 11.43 2,046 14,266 17,658 21,050 24,442 27,834 69 218
65 24,447 11.83 2,066 12,412 15,804 19,196 22,588 25,980 71 221
67 25,504 12.23 2,085 10,559 13,951 17,343 20,735 24,127 73 224
69 26,268 12.55 2,093 8,645 12,037 15,429 18,821 22,213 75 225
71 27,031 12.87 2,100 6,732 10,124 13,516 16,908 20,300 76 225
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 21,933 10.13 2,166 13,570 16,962 20,354 23,746 27,138 73 250
65 23,193 10.54 2,201 11,882 15,274 18,608 22,058 25,450 76 254
67 24,452 10.93 2,237 10,194 13,586 16,978 20,370 23,762 80 257
69 25,272 11.24 2,247 8,291 11,683 15,017 18,467 21,859 80 258
71 26,092 11.55 2,258 6,388 9,780 13,172 16,564 19,956 81 259
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 20,477 8.96 2,285 12,874 16,266 19,658 23,050 26,442 76 282
65 21,939 9.38 2,337 11,352 14,744 18,019 21,528 24,920 81 286
67 23,400 9.80 2,388 9,830 13,222 16,614 20,006 23,398 86 290
69 24,277 10.11 2,402 7,937 11,329 14,604 18,113 21,505 86 292
71 25,153 10.41 2,416 6,044 9,436 12,828 16,220 19,612 86 293
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 18,736 7.72 2,426 11,542 14,934 18,326 21,718 25,110 80 321
65 20,005 8.11 2,467 10,266 13,658 16,992 20,442 23,834 84 322
67 21,274 8.49 2,507 8,990 12,382 15,774 19,166 22,558 87 323
69 22,428 8.85 2,533 7,226 10,618 13,952 17,402 20,794 89 326
71 23,582 9.22 2,558 5,463 8,855 12,247 15,639 19,031 90 329
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 16,995 6.62 2,567 10,211 13,603 16,995 20,387 23,779 84 359
65 18,071 6.96 2,597 9,181 12,573 15,965 19,357 22,749 86 358
67 19,147 7.29 2,626 8,151 11,543 14,935 18,327 21,719 88 356
69 20,579 7.72 2,664 6,516 9,908 13,300 16,692 20,084 91 361
71 22,010 8.15 2,701 4,881 8,273 11,665 15,057 18,449 94 365
PERFORMANCE DATA - OPERATING PRESSURES
4
