Mitsubishi PUG36AYB User Manual

036-21534-001 Rev. B (0703)
Mitsubishi Electronics 2003 13
PL30+PUG30 (Indoor Air = 1060 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 28,888 11.20 2,580 19,060 22,646 27,632 32,619 36,205 68 229
65 29,670 11.23 2,591 15,065 19,181 23,298 27,415 31,532 69 230
67 30,473 11.72 2,601 13,951 17,537 22,523 27,510 31,096 70 230
69 31,880 11.91 2,622 10,492 14,609 18,726 22,843 26,960 72 233
71 32,071 12.14 2,643 8,857 12,443 17,430 22,416 26,002 74 235
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 26,930 9.86 2,732 18,001 21,587 26,573 31,560 35,146 70 261
65 28,148 10.13 2,779 15,670 19,256 24,242 29,229 32,815 72 265
67 29,436 10.41 2,827 13,339 16,925 21,912 26,898 30,484 75 269
69 30,672 10.79 2,843 10,988 14,574 19,561 24,548 28,134 77 270
71 31,361 10.97 2,859 8,638 12,224 17,211 22,197 25,783 79 272
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 24,972 8.66 2,883 16,942 20,528 25,514 30,501 34,087 73 292
65 26,626 8.97 2,968 13,778 17,894 21,869 26,128 30,245 76 300
67 28,400 9.30 3,054 12,727 16,313 21,300 26,287 29,873 80 307
69 29,464 9.61 3,065 9,633 13,750 17,725 21,983 26,100 82 308
71 30,652 9.97 3,076 8,419 12,005 16,992 21,978 25,564 84 308
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 22,952 8.16 2,811 15,447 19,033 24,020 29,006 32,592 76 331
65 24,279 8.09 3,001 12,460 16,577 20,623 24,810 28,927 79 336
67 26,034 8.16 3,191 11,853 15,439 20,426 25,413 28,999 82 342
69 27,220 8.41 3,237 8,771 12,887 16,933 21,121 25,238 85 344
71 28,953 8.82 3,284 7,625 11,211 16,198 21,185 24,771 88 347
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 20,932 7.64 2,740 13,952 17,538 22,525 27,512 31,098 80 369
65 21,932 6.60 3,034 11,143 15,259 19,376 23,493 27,610 82 373
67 23,668 7.11 3,328 10,979 14,565 19,552 24,539 28,125 84 377
69 24,976 7.33 3,410 7,908 12,025 16,142 20,259 24,375 88 381
71 27,254 7.80 3,492 6,832 10,418 15,405 20,391 23,977 92 385
PERFORMANCE DATA - OPERATING PRESSURES
4
