Mitsubishi PUG36AYB User Manual

036-21534-001 Rev. B (0703)
14 Mitsubishi Electronics 2003
PL36+PUG36 (Indoor Air = 1060 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 36,541 12.08 3,025 22,847 26,595 31,808 37,020 40,768 72 228
65 37,192 12.13 3,056 18,884 24,044 29,205 34,365 39,526 73 225
67 38,745 12.55 3,087 17,362 21,110 26,323 31,535 35,283 75 221
69 39,963 12.87 3,098 13,152 18,313 23,473 28,634 33,794 76 222
71 41,388 13.32 3,108 12,568 16,316 21,528 26,740 30,488 77 223
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 34,206 10.69 3,200 21,830 25,578 30,790 36,002 39,751 74 255
65 35,284 10.83 3,257 19,156 22,904 28,117 33,329 37,077 77 255
67 37,172 11.21 3,315 16,483 20,231 25,443 30,656 34,404 79 256
69 38,448 11.53 3,334 14,054 17,802 23,015 28,227 31,975 80 257
71 39,576 11.81 3,352 11,625 15,374 20,586 25,798 29,546 81 258
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 31,871 9.44 3,375 20,812 24,561 29,773 34,985 38,733 77 281
65 33,377 9.65 3,459 17,271 22,431 27,413 32,752 37,912 80 286
67 35,600 10.05 3,542 15,604 19,352 24,564 29,776 33,524 82 291
69 36,933 10.35 3,569 12,075 17,236 22,218 27,557 32,717 84 292
71 37,765 10.50 3,596 10,683 14,431 19,644 24,856 28,604 86 293
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 29,080 8.16 3,565 19,181 22,929 28,141 33,354 37,102 80 320
65 30,435 8.34 3,650 15,619 20,779 25,851 31,100 36,261 84 324
67 32,683 8.75 3,735 14,539 18,287 23,499 28,712 32,460 88 329
69 34,120 9.02 3,785 10,994 16,155 21,226 26,476 31,636 89 330
71 35,694 9.31 3,834 9,784 13,532 18,745 23,957 27,705 90 332
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 26,288 7.00 3,755 17,550 21,298 26,510 31,722 35,471 84 359
65 27,493 7.13 3,841 13,967 19,128 24,288 29,449 34,609 88 363
67 29,767 7.58 3,927 13,474 17,223 22,435 27,647 31,395 93 366
69 31,307 7.92 4,000 9,913 15,074 20,234 25,395 30,555 94 369
71 33,622 8.26 4,073 8,885 12,633 17,846 23,058 26,806 95 371
PERFORMANCE DATA - OPERATING PRESSURES
