Mitsubishi PUG36AYB User Manual

036-21534-001 Rev. B (0703)
Mitsubishi Electronics 2003 15
PL42+PUG42 (Indoor Air = 1060 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 41,051 11.01 3,729 21,748 27,504 32,153 36,802 42,558 61 208
65 42,003 11.21 3,747 19,211 24,967 29,777 34,586 40,342 62 209
67 42,955 11.41 3,765 16,674 22,430 27,400 32,370 38,126 63 210
69 43,906 11.61 3,782 14,136 19,893 25,023 30,154 35,911 64 211
71 44,858 11.81 3,798 11,599 17,356 22,647 27,938 33,695 65 212
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 40,028 10.04 3,986 21,614 27,371 31,811 36,252 42,009 65 239
65 40,990 10.23 4,007 19,015 24,772 29,447 34,122 39,878 66 240
67 41,977 10.24 4,099 16,417 22,173 27,082 31,992 37,748 67 241
69 42,913 10.61 4,045 13,818 19,574 24,718 29,861 35,618 68 242
71 43,875 10.80 4,063 11,219 16,975 22,353 27,731 33,487 69 244
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 39,004 9.19 4,244 21,481 27,237 31,470 35,703 41,459 69 270
65 39,976 9.37 4,266 18,820 24,577 29,117 33,658 39,414 70 271
67 41,000 9.25 4,432 16,160 21,916 26,765 31,613 37,369 71 273
69 41,920 9.73 4,308 13,499 19,255 24,412 29,568 35,325 72 274
71 42,892 9.91 4,328 10,839 16,595 22,059 27,523 33,280 74 275
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 36,480 8.11 4,497 20,358 26,115 30,074 34,033 39,789 71 305
65 37,581 8.30 4,528 17,876 23,633 27,950 32,267 38,023 73 306
67 38,709 8.36 4,631 15,394 21,150 25,826 30,501 36,258 75 308
69 39,784 8.67 4,588 12,912 18,668 23,702 28,736 34,492 76 309
71 40,886 8.86 4,616 10,429 16,186 21,578 26,970 32,726 78 311
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 33,955 7.15 4,749 19,236 24,993 28,678 32,362 38,119 74 340
65 35,186 7.35 4,790 16,932 22,689 26,782 30,876 36,632 76 342
67 36,417 7.54 4,830 14,628 20,385 24,887 29,389 35,146 78 343
69 37,649 7.74 4,867 12,324 18,081 22,992 27,903 33,659 80 345
71 38,880 7.93 4,903 10,020 15,776 21,096 26,416 32,173 83 346
PERFORMANCE DATA - OPERATING PRESSURES
4
