Mitsubishi PUG36AYB User Manual

036-21534-001 Rev. B (0703)
Mitsubishi Electronics 2003 17
PC30+PUG30 (Indoor Air = 830 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 30,312 11.62 2,609 20,799 24,712 30,154 35,596 39,509 71 228
65 31,133 11.65 2,620 15,807 20,127 24,447 28,766 33,086 72 229
67 31,975 12.16 2,630 15,224 19,137 24,579 30,021 33,934 73 229
69 33,452 12.36 2,651 11,010 15,329 19,649 23,969 28,288 75 232
71 33,652 12.59 2,672 9,665 13,579 19,020 24,462 28,375 77 234
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 28,257 10.23 2,762 19,644 23,557 28,999 34,440 38,354 74 260
65 29,536 10.51 2,811 17,100 21,013 26,455 31,897 35,810 76 264
67 30,887 10.80 2,859 14,556 18,470 23,911 29,353 33,266 78 268
69 32,184 11.19 2,875 11,991 15,905 21,346 26,788 30,701 80 269
71 32,907 11.38 2,891 9,426 13,340 18,781 24,223 28,136 82 271
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 26,203 8.99 2,915 18,488 22,401 27,843 33,285 37,198 76 291
65 27,939 9.31 3,002 14,457 18,776 22,947 27,416 31,736 80 299
67 29,800 9.65 3,088 13,889 17,802 23,244 28,686 32,599 83 306
69 30,916 9.98 3,099 10,108 14,428 18,598 23,067 27,387 85 307
71 32,163 10.34 3,110 9,187 13,101 18,542 23,984 27,897 88 307
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 24,083 8.47 2,843 16,857 20,770 26,212 31,654 35,567 80 330
65 25,476 8.39 3,035 13,074 17,394 21,639 26,033 30,353 82 335
67 27,318 8.47 3,227 12,935 16,848 22,290 27,732 31,645 85 341
69 28,562 8.72 3,274 9,203 13,523 17,768 22,162 26,482 88 343
71 30,380 9.15 3,321 8,321 12,235 17,676 23,118 27,032 91 346
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 21,964 7.93 2,770 15,226 19,139 24,581 30,023 33,936 83 368
65 23,013 6.85 3,068 11,692 16,012 20,331 24,651 28,971 85 372
67 24,835 7.38 3,365 11,981 15,895 21,337 26,778 30,692 87 376
69 26,207 7.60 3,448 8,298 12,618 16,938 21,257 25,577 91 380
71 28,598 8.10 3,531 7,455 11,369 16,811 22,252 26,166 95 384
PERFORMANCE DATA - OPERATING PRESSURES
