Mitsubishi PUG42AYB User Manual

036-21534-001 Rev. B (0703)
18 Mitsubishi Electronics 2003
PC36+PUG36 (Indoor Air = 1100 CFM)
75 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 36,952 12.08 3,059 24,108 28,063 33,563 39,063 43,018 73 228
65 37,610 12.17 3,090 19,096 24,314 29,533 34,751 39,970 75 225
67 39,180 12.55 3,122 18,321 22,276 27,776 33,276 37,231 76 221
69 40,412 12.90 3,133 13,300 18,519 23,737 28,956 34,174 77 222
71 41,853 13.32 3,143 13,261 17,216 22,716 28,216 32,171 78 223
85 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 34,591 10.69 3,236 23,035 26,990 32,490 37,990 41,945 76 255
65 35,681 10.83 3,294 20,214 24,169 29,669 35,169 39,124 78 255
67 37,590 11.21 3,352 17,393 21,348 26,848 32,348 36,303 80 256
69 38,880 11.53 3,371 14,830 18,785 24,285 29,785 33,740 81 257
71 40,021 11.81 3,390 12,267 16,222 21,722 27,222 31,177 83 258
95 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 32,229 9.44 3,413 21,961 25,916 31,416 36,916 40,871 78 281
65 33,752 9.65 3,498 17,465 22,683 27,721 33,120 38,338 81 286
67 36,000 10.05 3,582 16,465 20,420 25,920 31,420 35,375 84 291
69 37,348 10.35 3,609 12,211 17,429 22,468 27,866 33,085 85 292
71 38,189 10.50 3,637 11,273 15,228 20,728 26,228 30,183 87 293
105 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 29,406 8.16 3,605 20,240 24,195 29,695 35,195 39,150 82 320
65 30,777 8.34 3,691 15,794 21,013 26,141 31,450 36,668 85 324
67 33,051 8.75 3,777 15,342 19,297 24,797 30,297 34,252 89 329
69 34,504 9.02 3,827 11,118 16,336 21,465 26,773 31,992 90 330
71 36,095 9.31 3,878 10,324 14,279 19,779 25,279 29,234 92 332
115 °F Outdoor Air Temperature
Indoor Wet
Bulb (°F)
Cooling
Capacity
(Btu/hr)
EER
Total
Power
(Watts)
Net Sensible Cooling Capacity (Btu/hr)
Pressures
(psig)
Indoor Dry Bulb (°F)
70 75 80 85 90 Suction Discharge
63 26,583 7.00 3,797 18,519 22,474 27,974 33,474 37,429 85 359
65 27,802 7.16 3,884 14,124 19,343 24,561 29,780 34,998 90 363
67 30,101 7.58 3,972 14,218 18,173 23,673 29,173 33,128 94 366
69 31,659 7.83 4,045 10,025 15,243 20,462 25,680 30,898 95 369
71 34,000 8.26 4,118 9,376 13,331 18,831 24,331 28,286 96 371
PERFORMANCE DATA - OPERATING PRESSURES
4
