5.2 High Performance Model QCPU, Process CPU and Redundant CPU
5.2.4 Standard RAM
5
MEMORIES AND FILES HANDLED BY CPU MODULE
(4) Write to standard RAM
To write data to the standard RAM, choose [Online] [Write to PLC] on GX
Developer.
Select "Standard RAM" as the target memory on the Write to PLC screen and write
data to the PLC.
POINT
The file size has the minimum unit. ( Section 5.4.4)
The occupied memory capacity may be greater than the actual file size.
Note that as the number of files rises, the difference between the occupied
memory capacity and actual file size increases.
Diagram 5.20 Write to PLC screen
