FUNCTIONS
6.6 Remote Operation
6.6.1 Remote RUN/STOP
6 - 25
1
Overview
2
Performance Specification
3
Sequence Program Configuration and Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files Handled by CPU Module
6
Functions
7
Communication using built-in Ethernet ports of CPU module
8
Communication with Intelligent Function Module
(b) Method by GX Developer or external device using MC protocol
RUN/STOP of the CPU module can be executed by performing remote RUN/
STOP operation with GX Developer or external device using MC protocol.
Operate GX Developer by choosing [Online] [Remote operation].
Execute remote RUN/STOP from an external device using the MC protocol
command.
Q Corresponding MELSEC Communication Protocol Reference Manual
(c) Method with link dedicated instructions of the CC-Link IE controller network
module or MELSECNET/H network module
The remote RUN/STOP operation by the link dedicated instructions of the CC-
Link IE controller network module or MELSECNET/H network module can change
the RUN/STOP status of the CPU module. Refer to the following manuals for
details.
CC-Link IE Controller Network Reference Manual
Q Corresponding MELSECNET/H Network System Reference Manual
(PLC to PLC network)
Figure 6.16 Remote RUN/STOP by GX Developer or external device
GX Developer
or
External device
Remote STOP
command
Remote RUN
command
RUN/STOP
status
Step 0
ON
OFF
OFF
RUN
STOP
END
STOP status
ON
Step 0
END
