6
FUNCTIONS
6.11 Monitor Function
6.11.4 Executional conditioned device test
6 - 67
1
Overview
2
Performance
Specification
3
Sequence Program
Configuration and
Execution Conditions
4
I/O Nunber Assignment
5
Memories and Files
Handled by CPU Module
6
Functions
7
Communication using
built-in Ethernet ports of
CPU module
8
Communication with
Intelligent Function
Module
(2) Specifiable devices and number of settable devices
* 1: The extended data register (D) is also included.
* 2: The extended link register (W) is also included.
(3) Checking execution status of Executional conditioned device test
The execution status of registered Executional conditioned device test can be
checked in three different ways:
• By the flash of the MODE LED in green
• By the ON status of the first bit of SD840 (Debug function usage)
( Appendix 2)
• By the display on the screen for checking the registration status in GX Developer
( (4)(d) in this section)
POINT
1. The MODE LED also flashes in green when the Forced ON/OFF function for
external I/O is used. To check the execution status using the MODE LED,
check the status of the Forced ON/OFF function as well. ( Section 6.11.3)
2. When using SD840 to check the execution status, remind that SD840 is used
to check the status for the Forced ON/OFF function for external I/O as well.
Table6.22 Specifiable devices and number of settable devices
Type Specifiable device Number of settable devices
Bit device
X, Y, M, L, B, F, SB, V, SM, T (contact), ST (contact), C
(contact), J \ X, J \ Y, J \ B, J \ SB, FX, FY, DX, and DY
32 in total (maximum)
Word device
T (current value), ST (current value), C (current value), D
*1
,
SD, W
*2
, SW, R, ZR, Z, U \ G , U3E \ G , J \ W ,
J \ SW , and FD
Digit-specified bit device:
X, Y, M, L, F, SM, V, B, SB, J \ X, J \ Y, J \ B, and J \ SB
Indirect specification (@D0):
D, SD, W, SW, R, and ZR (devices specified with @)
To Next Page
