5
- 6
5.1 Basic Model QCPU
5.1.2 Program memory
5
MEMORIES AND FILES USED IN CPU MODULE
(4)
Wri
te to program memory
T
o write data to the progr
am memory
, choose [Online]
[Write to PLC] on GX
Developer
.
Select "Program memory/Device memory" as the t
arget memory on the Write to PLC
screen and write dat
a
to the PLC.
POINT
The file size has the mini
mum unit. (
Section 5.4.4)
The occupied memory ca
pacity may be
greate
r than the actual file size.
Figure 5.4 Write to PLC screen
229
231
