Appendix 2 Special Register List
APPENDICES
(5) Memory card
TableApp.23 Special register
Number Name Meaning Explanation
Set by
(When set)
Corres-
ponding
ACPU
D9
Corresponding CPU
SD600
Memory card
models
Memory card
models
• Indicates memory card model installed
S (Initial and
card removal)
New
Qn(H)
QnPH
QnPRH
Memory card A
models
Memory card A
models
• Indicates memory card A model installed
S (Initial and
card removal)
New QnA
SD602
Drive 1
(Standard
RAM) capacity
Drive 1 capacity • Drive 1 capacity is stored in 1 kbyte units.
S (Initial and
card removal)
New
Qn(H)
QnPH
QnPRH
S (Initial and
card removal)
New QnA
SD603
Drive 2
(Standard
ROM) capacity
Drive 2 capacity • Drive 2 capacity is stored in 1 kbyte units.
S (Initial and
card removal)
New
Qn(H)
QnPH
QnPRH
S (Initial and
card removal)
New QnA
SD604
Memory card
use conditions
Memory card use
conditions
• The use conditions for memory card (A) are stored as bit patterns .
(In use when ON)
• The significance of these bit patterns is indicated below:
S (Status
change)
New
Qn(H)
QnPH
QnPRH
Memory card A
use conditions
Memory card A
use conditions
• The use conditions for memory card A are stored as bit patterns.
(In use when ON)
• The significance of these bit patterns is indicated below:
S (Status
change)
New QnA
b4
b3 b0
0
0: Does not exist
(1: SRAM)
b8 b7b15
to to to
Drive 1
(RAM)
model
Drive 2
(ROM)
model
0: Does not exist
1: SRAM
2: ATA FLASH
3: Flash ROM
b4 b3 b0
0
b8 b7b15
Drive 1
Drive 2
0: Does not exist
0: Does not exist
1: SRAM(RAM) model
(ROM) model
2: E PROM
3: Flash ROM
2
to to to
b0 : Boot operation (QBT)
b1 : Parameters (QPA)
b2 : Device comments (QCD)
b3 : Device initial value (QDI)
b4 : File register R (QDR)
b5 : Trace (QTS)
b6 : Not used
b7 : Not used
b8 : Not used
b9 : CPU fault history (QFD)
b10 : SFC trace (QTR)
b11 : Local device (QDL)
b12 : Not used
b13 : Not used
b14 : Not used
b15 : Not used
b0 : Boot operation (QBT)
b1 : Parameters (QPA)
b2 : Device comments (QCD)
b3 : Device initial value (QDI)
b4 : File R (QDR)
b5 : Sampling trace (QTS)
b6 : Status latch (QTL)
b7 : Program trace (QTP)
b8 : Simulation data (QDS)
b9 : CPU fault history (QFD)
b10 : SFC trace (QTR)
b11 : Local device (QDL)
b12 : Not used
b13 : Not used
b14 : Not used
b15 : Not used
