5 - 59
MELSEC-Q
5 DATA USED FOR POSITIONING CONTROL
Setting Value, setting range
Value set with peripheral device
Setting value buffer memory
address
Servo amplifier setting invalid ( : Invalid, : Valid)
MR-
H-BN
MR-
H-BN4
MR-
J2-B
MR-
J2S-B
MR-
J2-Jr
MR-
J2M-B
Value set with sequence program
Default
value
Axis 1 Axis 2 Axis 3 Axis 4
0 to 4 3 30100 30200 30300 30400
0 to 1 0 30101 30201 30301 30401
3
3
3
3
Regenerative selection
brake option
0
H
Select the external
dynamic brake
1: is used to set up the setting
value.
(Hexadecimal)
0000
H
30102 30202 30302 30402
2: Set the parameter value and switch power off once (The parameter is transferred to servo amplifier from QD75), then switch it on
again to make that parameter setting valid.
3: Servo amplifier type of 400V is made the target.
