Appendix - 108
MELSEC-Q
APPENDICES
Buffer memory address
Axis 1 Axis 2 Axis 3 Axis 4
Item Memory area
26000 26050 27000 27050 28000 28050 29000 29050
Da.11
Shape
Da.12
Start data No.
Da.13
Special start instruction
Da.14
Parameter
1st point
26001 26051 27001 27051 28001 28051 29001 29051
2nd point
26002 26052 27002 27052 28002 28052 29002 29052
3rd point
to to to to to
26049 26099 27049 27099 28049 28099 29049 29099
50th point
Block start data
Da.15
Condition target
26100 27100 28100 29100
Da.16
Condition operator
26102
26103
27102
27103
28102
28103
29102
29103
Da.17
Address
26104
26405
27104
27405
28104
28405
29104
29405
Da.18
Parameter 1
26106
26107
27106
27107
28106
28107
29106
29107
Da.19
Parameter 2
1st item
26110 to 26119 27110 to 27119 28110 to 28119 29110 to 29119
2nd item
26120 to 26129 27120 to 27129 28120 to 28129 29120 to 29129
3rd item
to to to to to
26190 to 26199 27190 to 27199 28190 to 28199 29190 to 29199
10th item
Condition data
Starting block 0
26200 to 26299 27200 to 27299 28200 to 28299 29200 to 29299
Block start data
26300 to 26399 27300 to 27399 28300 to 28399 29300 to 29399
Condition data
Starting block 1
26400 to 26499 27400 to 27499 28400 to 28499 29400 to 29499
Block start data
26500 to 26599 27500 to 27599 28500 to 28599 29500 to 29599
Condition data
Starting block 2
26600 to 26699 27600 to 27699 28600 to 28699 29600 to 29699
Block start data
26700 to 26799 27700 to 27799 28700 to 28799 29700 to 29799
Condition data
Starting block 3
26800 to 26899 27800 to 27899 28800 to 28899 29800 to 29899
Block start data
26900 to 26999 27900 to 27999 28900 to 28999 29900 to 29999
Condition data
Starting block 4
Positioning data (Starting block data)
