Chapter 5 PERIODIC MAINTENANCE CHART
5-7
Every 24000
service
hours
Major overhaul (complete disassembly and inspection)
Change all O-rings, gaskets and seals.
½
Cylinder
heads and
valve mech-
anisms
Change inlet and exhaust valves, valve seats, valve guides, valve
rotators and valve cotters.
Inspect and change pushrods, rocker arm bushings, valve springs,
tappet rollers, tappet roller bushings, tappet shafts, tappet guides
and tappet guide set screws.
Cylinder liners Change.
Main bearings
Inspect caps and bolts, and change main bear-
ings.
Cam bushings
Inspect and change (in 2nd 24000-service-hour-
interval inspection and maintenance).
Pistons
Disassemble and inspect piston crown, and
change O-rings.
Connecting rods Change bolts and small-end bushings.
Crankshaft Inspect journals and pins, and change slingers.
Damper
Change (in 2nd 24000-service-hour-interval
inspection and maintenance).
Spring coupling
Disassemble and maintain (by spring coupling
manufacturer).
Timing gear
and front
gear
All shafts Inspect.
Rear idler gear
Inspect and change assemblies (including bush-
ings).
Change front idler bearing, camshaft roller bearing, front seal, rear
seal, front gear case gasket and rear gear case gasket.
Fuel system
Fuel injection
nozzles
Change nozzle holder assemblies.
Fuel injection
pump
Change plunger assembly and delivery valve.
Fuel feed pump
(trochoid type)
Change pump assembly.
Regulator valve Change.
Lubricating
system
Oil pump Change safety valve and spring.
Oil thermostat Change.
Oil pan Clean and change gasket.
Engine oil regu-
lator valve
Inspect and change.
Cooling
system
Water pump Change shaft and impeller.
Coolant ther-
mostat
Change.
Inlet and
exhaust
systems
Air cooler
Change element (in 2nd 24000-hour-interval
inspection and maintenance).
Exhaust pipes Inspect and change bellows.
Exhaust duct Change seal rings.
Governor
Actuator
Disassemble and maintain (by governor manu-
facturer).
Governor case Change bearings, O-rings and gaskets.
Control shaft Change oil seals.
Table 5-1 Periodic maintenance chart for engine in regular use (5 / 5)
Service
interval
Service item Service contents Page
To Next Page
