3-11
Chapter 3 OPERATION
Fuel Tank - Drain Water
If fuel gets mixed with particles of foreign material
such as dust, dirt, or water, it can cause not only
decrease of output but also malfunctions of the fuel
system. To avoid such a problem, drain fuel tank as
described below.
Note: If the specification of fuel tank differs from the
contents of this operation manual, follow the fuel
tank manufacturer's operation manual.
1. Place the oil pan (capacity of 2 liters [0.5 US gal] or
more) under the drain cock of fuel tank.
2. Open the drain cock of fuel tank and drain fuel at
least 1 to 2 liters [0.3 to 0.5 US gal].
3. After checking that there is no water or foreign ob-
ject in the drained fuel, close the drain cock.
Fig. 3-15 Fuel Tank - Drain Water
Fuel Control Link - Check
Check fuel control link for smooth movement.
Push the manual stop lever to the fuel increase direc-
tion, check the movement of the rack cancel spring.
Then loosen your grip on the lever little by little, mak-
ing sure the manual stop lever returns to the no fuel
injection position smoothly.
Also check all ball joints for looseness and play.
Fig. 3-16 Check Fuel Control Link
When handling fuel, make sure there are no open flames, heaters or other fire hazards. Wipe off any spilled fuel
completely. Spilled fuel can ignite and cause a fire.
Do not remove the strainer when filling the fuel. For fuel to be used, refer to "FUEL" (4-1).
The following is a common procedure to drain water from fuel tanks, although the fuel tank actually installed may
exactly the same.
Drain cock
Water
Rack cancel spring
Manual stop lever
Ball joint
To Next Page
