128
-
'16 • SCM-T-199
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B Min.
Standard
Max.
1
unit
20 2.0 - 1.5 2.0 2.7 560 620 880 3.1 3.0 2.8
25 2.5 - 1.5 2.5 3.2 560 710 1040 3.5 3.4 3.2
35 3.5 - 1.5 3.5 3.7 560 1030 1200 5.1 4.9 4.7
2
units
20 + 20 2.00 2.00 3.0 4.0 5.6 600 880 1750 4.4 4.2 4.0
20 + 25 2.00 2.50 3.0 4.5 5.8 600 1090 2030 5.3 5.0 4.8
20 + 35 1.89 3.31 3.0 5.2 5.8 600 1500 2030 7.0 6.7 6.5
25 + 25 2.50 2.50 3.0 5.0 5.8 600 1340 2030 6.4 6.1 5.8
25 + 35 2.17 3.03 3.0 5.2 5.8 600 1500 2030 7.0 6.7 6.5
(c) Indoor unit except SRK＊＊ ZMX-S and SKM＊＊ ZSP-S models
<Cooling>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B Min.
Standard
Max.
1
unit
20 3.0 - 1.3 3.0 3.5 520 900 1070 4.4 4.2 4.0
25 3.4 - 1.3 3.4 4.0 520 1070 1210 5.2 5.0 4.8
35 4.5 - 1.3 4.5 4.8 520 1340 1450 6.5 6.3 6.0
2
units
20 + 20 2.25 2.25 2.0 4.5 6.1 550 930 1700 4.5 4.3 4.2
20 + 25 2.36 2.94 2.0 5.3 6.1 550 1240 1700 5.9 5.6 5.4
20 + 35 2.11 3.69 2.0 5.8 6.1 550 1330 1700 6.2 5.9 5.7
25 + 25 2.90 2.90 2.0 5.8 6.1 550 1330 1700 6.2 5.9 5.7
25 + 35 2.42 3.38 2.0 5.8 6.1 550 1330 1700 6.2 5.9 5.7
<Heating>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B Min.
Standard
Max.
1
unit
20 3.0 - 1.3 3.0 3.5 520 950 1070 4.6 4.4 4.2
25 3.4 - 1.3 3.4 4.0 520 1020 1210 5.0 4.8 4.6
35 4.5 - 1.3 4.5 4.8 520 1390 1450 6.8 6.5 6.2
2
units
20 + 20 2.25 2.25 2.0 4.5 6.1 550 1020 1700 5.0 4.8 4.6
20 + 25 2.36 2.94 2.0 5.3 6.1 550 1310 1700 6.2 5.9 5.7
20 + 35 2.11 3.69 2.0 5.8 6.1 550 1400 1700 6.5 6.3 6.0
25 + 25 2.90 2.90 2.0 5.8 6.1 550 1400 1700 6.5 6.3 6.0
25 + 35 2.42 3.38 2.0 5.8 6.1 550 1400 1700 6.5 6.3 6.0
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B Min.
Standard
Max.
1
unit
20 2.0 - 1.5 2.0 2.7 560 620 880 3.1 3.0 2.8
25 2.5 - 1.5 2.5 3.2 560 710 1040 3.5 3.4 3.2
35 3.5 - 1.5 3.5 3.7 560 1030 1200 5.1 4.9 4.7
2
units
20 + 20 2.00 2.00 3.0 4.0 5.6 600 880 1750 4.4 4.2 4.0
20 + 25 2.00 2.50 3.0 4.5 5.8 600 1090 2030 5.3 5.0 4.8
20 + 35 1.89 3.31 3.0 5.2 5.8 600 1500 2030 7.0 6.7 6.5
25 + 25 2.50 2.50 3.0 5.0 5.8 600 1340 2030 6.4 6.1 5.8
25 + 35 2.17 3.03 3.0 5.2 5.8 600 1500 2030 7.0 6.7 6.5
(c) Indoor unit except SRK＊＊ ZMX-S and SKM＊＊ ZSP-S models
<Cooling>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B Min.
Standard
Max.
1
unit
20 3.0 - 1.3 3.0 3.5 520 900 1070 4.4 4.2 4.0
25 3.4 - 1.3 3.4 4.0 520 1070 1210 5.2 5.0 4.8
35 4.5 - 1.3 4.5 4.8 520 1340 1450 6.5 6.3 6.0
2
units
20 + 20 2.25 2.25 2.0 4.5 6.1 550 930 1700 4.5 4.3 4.2
20 + 25 2.36 2.94 2.0 5.3 6.1 550 1240 1700 5.9 5.6 5.4
20 + 35 2.11 3.69 2.0 5.8 6.1 550 1330 1700 6.2 5.9 5.7
25 + 25 2.90 2.90 2.0 5.8 6.1 550 1330 1700 6.2 5.9 5.7
25 + 35 2.42 3.38 2.0 5.8 6.1 550 1330 1700 6.2 5.9 5.7
<Heating>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B Min.
Standard
Max.
1
unit
20 3.0 - 1.3 3.0 3.5 520 950 1070 4.6 4.4 4.2
25 3.4 - 1.3 3.4 4.0 520 1020 1210 5.0 4.8 4.6
35 4.5 - 1.3 4.5 4.8 520 1390 1450 6.8 6.5 6.2
2
units
20 + 20 2.25 2.25 2.0 4.5 6.1 550 1020 1700 5.0 4.8 4.6
20 + 25 2.36 2.94 2.0 5.3 6.1 550 1310 1700 6.2 5.9 5.7
20 + 35 2.11 3.69 2.0 5.8 6.1 550 1400 1700 6.5 6.3 6.0
25 + 25 2.90 2.90 2.0 5.8 6.1 550 1400 1700 6.5 6.3 6.0
25 + 35 2.42 3.38 2.0 5.8 6.1 550 1400 1700 6.5 6.3 6.0
<Heating>
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B Min.
Standard
Max.
1
unit
20 2.0 - 1.5 2.0 2.7 560 620 880 3.1 3.0 2.8
25 2.5 - 1.5 2.5 3.2 560 710 1040 3.5 3.4 3.2
35 3.5 - 1.5 3.5 3.7 560 1030 1200 5.1 4.9 4.7
2
units
20 + 20 2.00 2.00 3.0 4.0 5.6 600 880 1750 4.4 4.2 4.0
20 + 25 2.00 2.50 3.0 4.5 5.8 600 1090 2030 5.3 5.0 4.8
20 + 35 1.89 3.31 3.0 5.2 5.8 600 1500 2030 7.0 6.7 6.5
25 + 25 2.50 2.50 3.0 5.0 5.8 600 1340 2030 6.4 6.1 5.8
25 + 35 2.17 3.03 3.0 5.2 5.8 600 1500 2030 7.0 6.7 6.5
(c) Indoor unit except SRK＊＊ ZMX-S and SKM＊＊ ZSP-S models
<Cooling>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B Min.
Standard
Max.
1
unit
20 3.0 - 1.3 3.0 3.5 520 900 1070 4.4 4.2 4.0
25 3.4 - 1.3 3.4 4.0 520 1070 1210 5.2 5.0 4.8
35 4.5 - 1.3 4.5 4.8 520 1340 1450 6.5 6.3 6.0
2
units
20 + 20 2.25 2.25 2.0 4.5 6.1 550 930 1700 4.5 4.3 4.2
20 + 25 2.36 2.94 2.0 5.3 6.1 550 1240 1700 5.9 5.6 5.4
20 + 35 2.11 3.69 2.0 5.8 6.1 550 1330 1700 6.2 5.9 5.7
25 + 25 2.90 2.90 2.0 5.8 6.1 550 1330 1700 6.2 5.9 5.7
25 + 35 2.42 3.38 2.0 5.8 6.1 550 1330 1700 6.2 5.9 5.7
<Heating>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit
capacity (kW)
Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B Min.
Standard
Max.
1
unit
20 3.0 - 1.3 3.0 3.5 520 950 1070 4.6 4.4 4.2
25 3.4 - 1.3 3.4 4.0 520 1020 1210 5.0 4.8 4.6
35 4.5 - 1.3 4.5 4.8 520 1390 1450 6.8 6.5 6.2
2
units
20 + 20 2.25 2.25 2.0 4.5 6.1 550 1020 1700 5.0 4.8 4.6
20 + 25 2.36 2.94 2.0 5.3 6.1 550 1310 1700 6.2 5.9 5.7
20 + 35 2.11 3.69 2.0 5.8 6.1 550 1400 1700 6.5 6.3 6.0
25 + 25 2.90 2.90 2.0 5.8 6.1 550 1400 1700 6.5 6.3 6.0
25 + 35 2.42 3.38 2.0 5.8 6.1 550 1400 1700 6.5 6.3 6.0
<Heating>
<Heating>
(c) Indoor unit except SRK
ZMX-S and SKM
ZSP-S models
<Cooling>
<Heating>
