DUCT JOINT FOR FDTC
PJZ012D073
Duct joint
1
Screw
6
Insulation 1
(120 × 54)
1
Insulation 2
(40 × 60)
2
●
This product is used by assembling on the spacer (TC-OAS-E)
●
Confirm the following parts are included:
1.Before installation
●
Fix the product on the spacer (TC-OAS-E) as shown below.
●
For the installation method, refer to the installation manual of the spacer.
2.Regarding the use of this product
Duct joint
Screw
Spacer
Lid
10.8 Duct joint (FDTC only)
PJZ012D073
