133
-
'16 • SCM-T-199
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B C Min.
Standard
max.
1
unit
20 2.0 - - 1.8 2.0 2.7 500 580 900 2.9 2.8 2.6
25 2.5 - - 1.8 2.5 3.2 500 760 1070 3.8 3.6 3.5
35 3.5 - - 1.8 3.5 3.7 500 1140 1230 5.7 5.4 5.2
50 5.0 - - 1.8 5.0 5.3 500 1790 2000 8.4 8.0 7.7
2
units
20 + 20 2.00 2.00 - 3.0 4.0 5.6 570 950 1800 4.7 4.5 4.3
20 + 25 1.91 2.39 - 3.0 4.3 5.8 570 1110 1980 5.5 5.3 5.1
20 + 35 1.82 3.18 - 3.0 5.0 6.1 570 1490 2070 7.2 6.9 6.6
20 + 50 1.71 4.29 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
25 + 25 2.35 2.35 - 3.0 4.7 6.1 570 1320 2070 6.4 6.2 5.9
25 + 35 2.21 3.09 - 3.0 5.3 6.3 570 1660 2150 7.9 7.5 7.2
25 + 50 2.00 4.00 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
35 + 35 3.00 3.00 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
35 + 50 2.47 3.53 - 3.0 6.0 6.5 570 2040 2150 9.4 9.0 8.6
3
units
20 + 20 + 20 1.67 1.67 1.67 3.4 5.0 6.9 690 1120 2150 5.6 5.3 4.5
20 + 20 + 25 1.60 1.60 2.00 3.4 5.2 6.9 690 1200 2150 5.9 5.7 5.4
20 + 20 + 35 1.49 1.49 2.61 3.4 5.6 6.9 690 1370 2150 6.6 6.4 6.1
20 + 25 + 25 1.54 1.93 1.93 3.4 5.4 6.9 690 1300 2150 6.3 6.1 5.8
20 + 25 + 35 1.45 1.81 2.54 3.4 5.8 6.9 690 1470 2150 7.1 6.8 6.5
25 + 25 + 25 1.87 1.87 1.87 3.4 5.6 6.9 690 1370 2150 6.6 6.4 6.1
25 + 25 + 35 1.76 1.76 2.47 3.4 6.0 6.9 690 1540 2150 7.4 7.0 6.8
(c) Indoor unit except SRK＊＊ ZMX-S and SKM＊＊ ZSP-S models
<Cooling>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B C Min.
Standard
max.
1
unit
20 3.0 - - 1.4 3.0 3.5 480 1020 1100 5.1 4.9 4.6
25 3.4 - - 1.4 3.4 4.0 480 1180 1240 5.9 5.6 5.4
35 4.5 - - 1.4 4.5 4.8 480 1470 1490 7.3 6.9 6.7
50 5.8 - - 1.4 5.8 6.0 480 1910 2260 8.8 8.4 8.0
2
units
20 + 20 2.95 2.95 - 2.0 5.9 7.0 540 1510 2580 7.2 6.9 6.6
20 + 25 2.67 3.33 - 2.0 6.0 7.0 540 1560 2580 7.4 7.1 6.8
20 + 35 2.29 4.01 - 2.0 6.3 7.0 540 1650 2580 7.7 7.4 7.1
20 + 50 1.89 4.71 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
25 + 25 3.05 3.05 - 2.0 6.1 7.0 540 1590 2580 7.5 7.2 6.9
25 + 35 2.67 3.73 - 2.0 6.4 7.0 540 1680 2580 7.8 7.5 7.2
25 + 50 2.20 4.40 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
35 + 35 3.30 3.30 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
35 + 50 2.72 3.88 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
3
units
20 + 20 + 20 2.00 2.00 2.00 3.0 6.0 7.3 600 1340 2580 6.7 6.4 6.1
20 + 20 + 25 1.91 1.91 2.38 3.0 6.2 7.3 600 1430 2580 6.9 6.6 6.4
20 + 20 + 35 1.76 1.76 3.08 3.0 6.6 7.3 600 1600 2580 7.6 7.2 6.9
20 + 25 + 25 1.83 2.29 2.29 3.0 6.4 7.3 600 1510 2580 7.2 6.9 6.6
20 + 25 + 35 1.70 2.13 2.98 3.0 6.8 7.3 600 1660 2580 7.8 7.4 7.1
25 + 25 + 25 2.20 2.20 2.20 3.0 6.6 7.3 600 1600 2580 7.6 7.2 6.9
25 + 25 + 35 2.06 2.06 2.88 3.0 7.0 7.3 600 1730 2580 8.0 7.7 7.3
<Heating>
Indoor unit
combination
Cooling capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B C Min.
Standard
max.
1
unit
20 2.0 - - 1.8 2.0 2.7 500 580 900 2.9 2.8 2.6
25 2.5 - - 1.8 2.5 3.2 500 760 1070 3.8 3.6 3.5
35 3.5 - - 1.8 3.5 3.7 500 1140 1230 5.7 5.4 5.2
50 5.0 - - 1.8 5.0 5.3 500 1790 2000 8.4 8.0 7.7
2
units
20 + 20 2.00 2.00 - 3.0 4.0 5.6 570 950 1800 4.7 4.5 4.3
20 + 25 1.91 2.39 - 3.0 4.3 5.8 570 1110 1980 5.5 5.3 5.1
20 + 35 1.82 3.18 - 3.0 5.0 6.1 570 1490 2070 7.2 6.9 6.6
20 + 50 1.71 4.29 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
25 + 25 2.35 2.35 - 3.0 4.7 6.1 570 1320 2070 6.4 6.2 5.9
25 + 35 2.21 3.09 - 3.0 5.3 6.3 570 1660 2150 7.9 7.5 7.2
25 + 50 2.00 4.00 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
35 + 35 3.00 3.00 - 3.0 6.0 6.3 570 2040 2150 9.4 9.0 8.6
35 + 50 2.47 3.53 - 3.0 6.0 6.5 570 2040 2150 9.4 9.0 8.6
3
units
20 + 20 + 20 1.67 1.67 1.67 3.4 5.0 6.9 690 1120 2150 5.6 5.3 4.5
20 + 20 + 25 1.60 1.60 2.00 3.4 5.2 6.9 690 1200 2150 5.9 5.7 5.4
20 + 20 + 35 1.49 1.49 2.61 3.4 5.6 6.9 690 1370 2150 6.6 6.4 6.1
20 + 25 + 25 1.54 1.93 1.93 3.4 5.4 6.9 690 1300 2150 6.3 6.1 5.8
20 + 25 + 35 1.45 1.81 2.54 3.4 5.8 6.9 690 1470 2150 7.1 6.8 6.5
25 + 25 + 25 1.87 1.87 1.87 3.4 5.6 6.9 690 1370 2150 6.6 6.4 6.1
25 + 25 + 35 1.76 1.76 2.47 3.4 6.0 6.9 690 1540 2150 7.4 7.0 6.8
(c) Indoor unit except SRK＊＊ ZMX-S and SKM＊＊ ZSP-S models
<Cooling>
Indoor unit
combination
Heating capacity (kW) Power consumption (W) Standard current (A)
Indoor unit capacity (kW) Total capacity (kW)
Min.
Standard
Max. 220V 230V 240V
A B C Min.
Standard
max.
1
unit
20 3.0 - - 1.4 3.0 3.5 480 1020 1100 5.1 4.9 4.6
25 3.4 - - 1.4 3.4 4.0 480 1180 1240 5.9 5.6 5.4
35 4.5 - - 1.4 4.5 4.8 480 1470 1490 7.3 6.9 6.7
50 5.8 - - 1.4 5.8 6.0 480 1910 2260 8.8 8.4 8.0
2
units
20 + 20 2.95 2.95 - 2.0 5.9 7.0 540 1510 2580 7.2 6.9 6.6
20 + 25 2.67 3.33 - 2.0 6.0 7.0 540 1560 2580 7.4 7.1 6.8
20 + 35 2.29 4.01 - 2.0 6.3 7.0 540 1650 2580 7.7 7.4 7.1
20 + 50 1.89 4.71 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
25 + 25 3.05 3.05 - 2.0 6.1 7.0 540 1590 2580 7.5 7.2 6.9
25 + 35 2.67 3.73 - 2.0 6.4 7.0 540 1680 2580 7.8 7.5 7.2
25 + 50 2.20 4.40 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
35 + 35 3.30 3.30 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
35 + 50 2.72 3.88 - 2.0 6.6 7.0 540 1740 2580 8.0 7.7 7.4
3
units
20 + 20 + 20 2.00 2.00 2.00 3.0 6.0 7.3 600 1340 2580 6.7 6.4 6.1
20 + 20 + 25 1.91 1.91 2.38 3.0 6.2 7.3 600 1430 2580 6.9 6.6 6.4
20 + 20 + 35 1.76 1.76 3.08 3.0 6.6 7.3 600 1600 2580 7.6 7.2 6.9
20 + 25 + 25 1.83 2.29 2.29 3.0 6.4 7.3 600 1510 2580 7.2 6.9 6.6
20 + 25 + 35 1.70 2.13 2.98 3.0 6.8 7.3 600 1660 2580 7.8 7.4 7.1
25 + 25 + 25 2.20 2.20 2.20 3.0 6.6 7.3 600 1600 2580 7.6 7.2 6.9
25 + 25 + 35 2.06 2.06 2.88 3.0 7.0 7.3 600 1730 2580 8.0 7.7 7.3
(c) Indoor unit except SRK
ZMX-S and SKM
ZSP-S models
<Cooling>
<Heating>
