'15 • SRK-T-172
SRK10CRV-S, S1
CRAE0215
END ITEM NO. : RMA002F060CA, 060CB
10 30 50 100 500 1000
1-6 RMA102A100 PANEL ASSY,FRONT 1 1 1 1 2
1 RKX122A300L PANEL,FRONT 1
2 RMA435A100 PANEL, AIR INLET 1 1 1 2 3
3 RKX437A300 FILTER,AIR 2 1 1 1 2
4 RKX129A013 CAP 2
5 RKX129A014 HOLDER,FILTER 2 1 1 1 2
6 RKX133A300 PLATE,ORNAMENT 1 1 1 1 2
7-20 RKX435A302G GRILLE ASSY,AIR OUT 1 1 1 2 3
7 RKX435A303A GRILLE,AIR OUTLET 1
8 RKX436A001 FLAP(A) 1 UPPER
9 RKX436A002 FLAP(B) 1 LOWER
10-11 RKX436A006A LOUVER ASSY 2
10 RKX436A005B LOUVER 6
11 RKX129A015A PLATE,CONNECTING 1
12 RKW935C200 COLLAR 6
13 RKX129A010 BRACKET,MOTOR (A) 1 1 1 1 2
14 RKX144A001A LINK 1 1 1 1 2
15 RKX144A002 CRANK(A) 1 1 1 1 2
16 RKX144A003 CRANK(B) 1 1 1 1 2
17 SSA512T096 MOTOR,STEPPING 1 1 1 1 2
18 RKS504A100G HARNESS ASSY 1 1 1 1 2
19 SSA423A102 HOSE,DRAIN 1
20 SSA326A047 PLUG 1
21 RKX111A001 BASE ASSY 1 1 1 1 2
22 SSA511J218A MOTOR,AC 1 1 1 1 2
23 SSA431G047 IMPELLER 1 1 1 2 4
24 SSA923C114 BEARING,PLANE 1 1 1 1 2
25 RKX129A005 COVER, MOTOR 1 1 1 1 2
26 RKX032A001 PLATE,INSTALLATION 1 1 1 1 2
27 RKX132A001A LID 1 1 1 2 4
28 SSA913A007A SCREW, TAP 4
NoteNo. Part No. Part Name
RE.Q
Recommendable Purchased Q'ty
