69
-
'15 • SRK-T-172
SRK10CRS-S, S1, S2, S3, S4, S5, S
6
CRAE0213
END ITEM NO. : RMA002F060AA, AB, AC, AD, AF, AG, AH
10 30 50 100 500 1000
1-6 RMA102A100B PANEL ASSY,FRONT 1 1 1 1 2 FOR S, S3, S4, S5, S6
1-6 RMA102A100H PANEL ASSY,FRONT 1 1 1 1 2 FOR S1, S2
1 RKX122A300M PANEL,FRONT 1
2 RMA435A100A PANEL, AIR INLET 1 1 1 2 3 FOR S, S3, S4, S5, S6
2 RKX435A300C PANEL, AIR INLET 1 1 1 2 3 FOR S1, S2
3 RKX437A300 FILTER,AIR 2 1 1 1 2
4 RKX129A013 CAP 2
5 RKX129A014 HOLDER,FILTER 2 1 1 1 2
6 RKX133A300 PLATE,ORNAMENT 1 1 1 1 2
7-27 RKX435A302F GRILLE ASSY,AIR OUT 1 1 1 2 3
7 RKX435A303A GRILLE,AIR OUTLET 1
8 RKX436A001 FLAP(A) 1 UPPER
9 RKX436A002 FLAP(B) 1 LOWER
10-11 RKX436A003B LOUVER ASSY .(R) 1 1 1 2 2
10 RKX436A005B LOUVER 6
11 RKX129A008A PLATE,CONNECTING(R) 1
12-13 RKX436A004B LOUVER ASSY .(L) 1
12 RKX436A005B LOUVER 6
13 RKX129A009A PLATE,CONNECTING(L) 1
14 RKW935C200 COLLAR 6
15 RKX129A010 BRACKET,MOTOR (A) 1 1 1 1 2
16 RKX129A011 BRACKET,MOTOR (B) 1
17 RKX129A012 BRACKET,MOTOR (C) 1
18 RKX144A001A LINK 1 1 1 1 2
19 RKX144A002 CRANK(A) 1 1 1 1 2
20 RKX144A003 CRANK(B) 1 1 1 1 2
21 RKW144A204 CRANK(C) 2 1 1 1 2
22 SSA512T096 MOTOR,STEPPING 3 1 1 1 2
23 RKS504A100G HARNESS ASSY 1 1 1 1 2 FOR FLAP
24 RKS504A100 HARNESS ASSY 1 1 1 1 2 FOR LOUVER(R)
25 RKS504A100L HARNESS ASSY 1 1 1 1 2 FOR LOUVER(L)
26 SSA423A102 HOSE,DRAIN 1
27 SSA326A047 PLUG 1
28 RKX111A001 BASE ASSY 1 1 1 1 2
29 SSA511J218A MOTOR,AC 1 1 1 1 2
30 SSA431G047 IMPELLER 1 1 1 2 4
31 SSA923C114 BEARING,PLANE 1 1 1 1 2
32 RKX129A005 COVER, MOTOR 1 1 1 1 2
33 RKX032A001 PLATE,INSTALLATION 1 1 1 1 2
34 RKX132A001A LID 1 1 1 2 4
35 SSA913A007A SCREW, TAP 4
NoteNo. Part No. Part Name
RE.Q
Recommendable Purchased Q'ty
