SRC10CRV-S, -S1
CRBE0290
END ITEM NO. : RMC003F060CA, 060CB
10 30 50 100 500 1000
1 RCV122A006C PANEL ASSY, FRONT 1 1 1 1 2
2 RCV123A001 PANEL ASSY,SIDE(R) 1 1 1 1 2
3 RCV124A500A PANEL ASSY, TOP 1 1 1 1 2
4 RCV132A003 COVER ASSY SERVICE 1 1 1 2 4
5 RCV435A002 GRILLE ASSY,AIR OUT 1 1 1 2 3
6 SSA944B036B HANDLE 1
7 SSA913A034F SCREW, TAP 25
8 SSA913A034G SCREW, TAP 1
9 RCV116A005B BRACKET ASSY 1
10 SSA511B822 MOTOR,AC 1 2 2 4 8
11 RCV116A003 BRACKET MOTOR(U) 1
12 RCV141A500 PLATE,BAFFLE 1
13 SSA431B254 PROPELLER 1 1 1 2 4
14 SSA914B007AC NUT, TH 1
15 RCV111A001F BASE ASSY 1 1 1 1 2
NoteNo. Part No. Part Name
RE.Q
Recommendable Purchased Q'ty
