35
-
'12 • SRK-T-125
SRK18CL / SRK18CL-3 / SRK18CL-6
END ITEM NO. : RMA002F019 / RMA002F019A / RMA002F019B
Recommendable Purchased Q'ty
10 30 50 100 500 1000
1-7 RMA102A101 PANEL ASSY, FRONT 1 1 1 1 2
1 RKY122A002 PANEL ASSY, FRONT 1 1 1 1 2
2 RKY435A003 GRILLE, AIR IN (TOP) 2 1 1 1 2
3 RMA435A010A PANEL ASSY, AIR IN 1 1 1 2 3
4 RKY437A001 FILTER, AIR 2 2 2 4 8
2PAC210A921YKR5 1 1 1 2
6 RKY133A008G PLATE ASSY, ORNAMENT 1 1 1 1 2
7 RKY011G001H LABEL, WIRING 1 1 1 2 4
8-21 RMA435A009 GRILLE ASSY, AIR OUT 1 1 1 2 3
8 RKY435A002 GRILLE, AIR OUT 1 1 1 2 3
9 RMA436A001 FLAP ASSY (U) 1 1 1 2 2 Upper
10 RMA436A003 FLAP ASSY (L) 1 1 1 2 2 Lower
11-12 RMA436A005 LOUVER ASSY 2 1 1 2 2
21REVUOL110A634YKR11 1 1 2 2
12 RMA129A002 PLATE, CONNECTING 2 1 1 1 2
4RALLOC002C539WKR31
14-18 RMA144A002 LINK ASSY ( R ) 1 1 1 1 2
14 RKY129A005 BRACKET, MOTOR ( R ) 1 1 1 1 2
1KNIL100A441YKR51 1 1 1 2
1)A(KNARC200A441YKR61 1 1 1 2
1)B(KNARC300A441YKR71 1 1 1 2
18 SSA512T096 MOTOR, STEPPING 1 1 1 1 2
19 RMA504A004 HARNESS ASSY 1 1 1 1 2
20 SSA423A102 HOSE, DRAIN 1
1GULP740A623ASS12
22 RKY111A001 BASE ASSY 1 1 1 1 2
23 SSA512T092 MOTOR, DC 1 1 1 1 2
1RELLEPMI050G134ASS42 1 1 2 4
25 SSA913A007 SCREW,TAP 4
26 SSA923C114 BEARING, PLANE 1 1 1 1 2
27 RKY129A037 BRACKET ASSY (U) 1 1 1 1 2
28 RKY129A038 BRACKET ASSY (L) 1 1 1 1 2
29 RKY032A001 PLATE, INSTALLATION 1 1 1 1 2
30 RKY129A034 COVER ASSY (PIPE) 1 1 1 1 2
1)R(DILA100A231YKR13 1 1 2 4
1)L(DIL200A231YKR23 1 1 2 4
NoteNo. Part No. Part Name RE.Q
