'13 • SRK-T-140
Model SRK25ZMP-S
Model
Item
SRK25ZMP-S
Indoor unit SRK25ZMP-S Outdoor unit SRC25ZMP-S
Power source 1 Phase, 220 - 240V, 50Hz
Operation
data
Nominal cooling capacity (range) kW 2.5 (0.9 (Min.) - 2.8 (Max.))
Nominal heating capacity (range) kW 2.8 (0.8 (Min.) - 3.9 (Max.))
Power
consumption
Cooling
kW
0.780 (0.25 - 1.01)
Heating 0.755 (0.20 - 1.43)
Max power consumption 1.65
Running
current
Cooling
A
3.9 / 3.8 / 3.6 (220 / 230 / 240 V)
Heating 3.8 / 3.7 / 3.5 (22 0 / 230 / 240 V)
Inrush current, max current 3.9 / 3.8 / 3.6 (220 / 230 / 240 V) Max. 9
Power factor
Cooling
%
90
Heating 89
EER Cooling 3.21
COP Heating 3.71
Sound power level
Cooling
dB(A)
59 60
Heating 58 59
Sound pressure level
Cooling Hi: 45 Me: 34 Lo: 23 47
Heating Hi: 43 Me: 34 Lo: 26 45
Silent mode sound pressure level — —
Exterior dimensions (Height x Width x Depth) mm 262 x 769 x 210 540 x 645(+57) x 275
Exterior appearance
(Munsell color)
Fine snow
(8.0Y 9.3/0.1) near equivalent
Stucco white
(4.2Y 7.5/1.1) near equivalent
Net weight kg 6.9 25
Compressor type & Q'ty — RM-B5077MDE5(Rotary type) x 1
Compressor motor (Starting method) kW — 0.75 (Inverter driven)
Refrigerant oil (amount, type) — 0.3 (DIAMOND FREEZE MA68)
Refrigerant (Type, amount, pre-charge length) kg R410A 0.655 in outdoor unit (incl. the amount for the piping of 10m)
Heat exchanger Louver fins & inner grooved tubing M fins & inner grooved tubing
Refrigerant control Capillary tubes + Electronic expansion valve
Fan type & Q'ty Tangential fan x 1 Propeller fan x 1
Fan motor (stating method) W 30 x1 (Direct drive) 24 x1 (Direct drive)
Air flow
Cooling
m
3
/min
Hi: 10.1 Me: 7.3 Lo: 4.2 26.0
Heating Hi: 9.5 Me: 7.3 Lo: 5.2 19.7
Available external static pressure Pa 0 0
Outside air intake Not possible —
Air filter, Quality / Quantity Polypropylene net (washable) —
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber sleeve (for fan motor & compressor)
Electric heater — —
Operation
control
Remote control Wireless-Remote control
Room temperature control Microcomputer thermostat
Operation display RUN: Green, TIMER: Yellow
Safety equipments
Compressor overheat protection, Overcurrent protection,
Frost protection, Serial signal error protection, Indoor fan motor error protection,
Heating overload protection (High pressure control), Cooling overload protection
Installation
data
Refrigerant piping size (O.D) mm Liquid line :
φ
6.35 (1/4") Gas line :
φ
9.52 (3/8")
Connecting method Flare connection Flare connection
Attached length of piping m Liquid line : 0.39 / Gas line : 0.32 —
Insulation for piping Necessary (Both sides), independent
Refrigerant line (one way) length m Max. 15
Vertical height diff. between O.U. and I.U.
m Max. 10 (Outdoor unit is higher) / Max. 10 (Outdoor unit is lower)
Drain hose
Hose connectable (VP 16) Holes
φ
20 x 2 pcs
Drain pump, max lift height mm — —
Recommended breaker size A 16
L.R.A. (Locked rotor ampere) A 3.9 / 3.8 / 3.6 (220 / 230 / 240 V)
Interconnecting wires Size x Core number 1.5mm
2
x 4 cores (Including earth cable) / Terminal block (Screw fixing type)
IP number IPX0 IPX4
Standard accessories Mounting kit
Option parts —
Note (1) The data are measured at the following conditions.
item
operation
Indoor air temperature Outdoor air temperature
Standards
DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
ISO5151-T1
Heating 20˚C — 7˚C 6˚C
(2) This air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound level indicates the value in an anechoic chamber. During operation these value are somewhat
higher due to ambient conditions.
(4) Select the breaker size according to the own national standard.
(5) The refrigerant quantity to be charged includes the refrigerant in 10 m connecting piping.
(purging is not required even for the short piping. )
If the piping length is longer, when it is 10 to 15 m, add 20 g refrigerant per meter.
The pipe length is 7.5m.
1. SPECIFICATIONS
