REFRIGERANT SYSTEM DIAGRAM
8
Pipe temperature thermistor/liquid
(TH2)
Distributor
with strainer (#50/#100)
Condenser/evaporator
temperature thermistor
(TH5)
Room temperature
thermistor (TH1)
Refrigerant flow in cooling
Refrigerant flow in heating
Strainer (#50)
Strainer (#50)
Heat exchanger
Refrigerant GAS pipe connection
(Flare)
Refrigerant LIQUID pipe connection
(Flare)
TPKA0A0241KA80A TPKA0A0301KA80A TPKA0A0361KA80A
