OPERATION
SUB GR. 2
Input data from measuring
equipment.
1 12.00 mm
2 26.25 mm
3 32.56 mm
X 0.92335 mm
R 2.77568 mm
PART NO.
DATE 2000/ 2/ 2
TIME 13: 35
NAME
*CONTROL LIMIT*
DATE 2000/ 2/ 2
TIME 13: 35
NO.OF SUB GR.
5
SAMPLE SIZE
8
X 4.1999 mm
X-UCL 6.9057 mm
X-LCL 1.4970 mm
R 2.6458 mm
R-UCL 6.8082 mm
R-LCL 6.8082 mm
DATE 2000/ 2/ 2
TIME 13: 35
*CLEAR SUB GR.*
*CLEAR ALL DATA*
TOL.LIMIT
DATA
DATA
DATA
STAT
STAT
PRINTER ON/OFF+
DATA
CE
CL
Function Operation Print
Measure next subgroup
Data input
Finish measurement of subgroup
and calculate X-R of subgroup
Calculation of control limits is
carried out from all the sub-group
data which has been input, and the
result is printed.
Time stamp
Cancels prior subgroup data. 'CE'
key is pressed after finishing
measurement of subgroup.
Clears measured data
'CL' key is pressed after finishing
measurement of subgroup.
