MJX Bugs 20EIS - Appendix; Product Parameters

Appendix
Product Parameters
Camera
Lens FOV: approx.130°
Aperture: f/2.0
Focal length: 2.8mm
Image Sensor 1/3 inch CMOS
Electronic Shutter Speed Electronic Shutter: 1/30s-1/10000s
ISO Range Photo: 100-3200 (Auto)
Video: 100-3200 (Auto)
Gimbal
Controllable Range Tilt: 0° to -90°
Aircraft
Gross Weight
(Battery and propellers included)
Dimensions
Max Ascent Speed
Bugs 20EIS: about 543g
380*380*125mm (length*width*height)
3m/s
Max Speed 40km/h
Max Descent Speed 2m/s
Flight Height Limitation 120m
Max Angular Velocity 200° /s
Max Tilt Angle 35°
GNSS GPS
Operating Temperature Range 0℃-40℃
Operating Frequency 2.4-2.4835GHz (Transmitter)
5.15-5.25GHz (FPV)
Hovering Accuracy Range
Indoor: Vertical ±0.3m
Horizontal ±0.3m
Outdoor: Vertical ±0.5m
Horizontal ±1.5m
Transmission Power (EIRP) 2.4GHZ≤20dBm
5GHz≤16dBm
Diagonal 280mm
-24-
