12
2. Tip-up and extractable armrests
Your folding electric wheelchair has tip-up armrests. To tip up the armrests, press the pin
and lift the armrest (fig.16-17), then press the rear pin to extract the armrest. (fig.19)
(fig.17) Pin (fig.18) (fig.19)
3. Adjusting the controller position
The controller of your folding electric wheelchair can be positioned on both the right and
the left. Insert the support bar into the specific guide positioned underneath the armrest
on the chosen side. Check that the distance of the drive knob is the best one for use.
• Loosen the knob
• Slide the controller bar into the desired position.
• Tighten the knob
4. Adjusting the roll-over protection height
• Raise the plastic disc
• Slide the tube of the roll-over protection wheels up to the desired height
• Block the tube in the corresponding position (fig.20)
(fig.20)
Note: There are five height adjustment positions, with one every 20 mm (fig.36)
